FreeHIL allows you to develop a sophisticated Hardware In the Loop (HIL) simulator using available tools like evaluation boards.

System Status

Component	Version
Base Project	v1.1.0
RobotFramework Source Code	v1.1.0
Embedded Software Source Code	v1.1.0

License

This project is licensed under the Apache License, Version 2.0.
For the full legal text, please see the LICENSE file in the repository.

Copyright 2026 Vahid Hasirchi

Video Tutorials

Here are the video guides for this project. Click the thumbnails to watch directly on YouTube:

Introduction to FreeHIL

▶

Robot Framework Source Code Guide

▶

Embedded Software Source Code Guide

▶

Peripheral Support (project v1.1.0)

✅ Digital Output: Up to 64 Channels
✅ Digital Input: Up to 64 Channels
✅ Analog Output: Up to 64 Channels
✅ Analog Input: Up to 64 Channels
✅ PWM Output: Up to 64 Channels
✅ PWM Input: Up to 64 Channels
✅ UART Interface: Up to 8 Channels (TX/RX)
✅ CAN Interface: Up to 8 Channels (TX/RX)

📂 Repositories

⭐ Base Project

This is the base FreeHIL repository containing the core logic of FreeHIL Embedded Software + Robot Framework Source Code

View Base Repo on GitHub

🏗️ Specific IDE & Microcontroller Projects

These repositories contain the FreeHIL core logic ported to specific IDEs and MCUs.

STM32CubeIDE + STM32H7B0VBTX Coming Soon

Initial porting of v1.1.0 in progress...

STM32CubeIDE + STM32H743IITX Coming Soon

Initial porting of v1.1.0 in progress...

Keil + STM32H7B0VBTX Coming Soon

Initial porting of v1.1.0 in progress...

Keil + STM32H743IITX Coming Soon

Initial porting of v1.1.0 in progress...

Preface

There are different types of Verification and Validation in the Product Life Cycle (PLC) of Embedded Systems.

Remarks: Simply put: Verification is "white box" testing, and Validation is "black box" testing.

Test Automation is crucial for both processes. Using frameworks like RobotFramework, you can execute test cases without human intervention.

Note: HIL simulators enhance quality by increasing testing scope. While testing on real hardware is ideal, HIL allows for testing scenarios that are otherwise limited by cost or safety.

FH Package Structure

The FH package is composed of 2 main parts:

FH Embedded Software (FH_Embedded): Ported to your microcontroller.
FH RobotFramework (FH_RobotFramework): Runs on the computer side, communicating via Serial (USB-to-Serial or RS485).

Example: Setting Digital Output 01

==============================================================================
                    ##### RobotFramework Example #####
==============================================================================
@{MessageData} =    Create List    ${DO01}    ${DO_Set}
&{Message}     =    Create Dictionary    DeviceAddress=${DeviceAddress_01}
                    Function=${Function_DO}    Command=${DO_Commands_SetStatus}
                    Data=@{MessageData}
${Result}    SendMessage    &{Message}

FH Embedded Software Details

The source code includes three main directories:

FH_Functions: The primary interface for users to insert MCU-specific code.
FH_Root: Core logic and message handling.
FH_Setup: Hardware initialization and configuration.

FH_Functions

This directory handles peripherals like Digital I/O (up to 64 channels), Analog I/O, PWM, UART, and CAN. Users should look for "Attentions" in the comments of files (e.g., FH_DO02.c) to find where to insert their specific driver code.

/**
  * @file
  * @brief
  *       <b>File Map:</b>\n
  *       <b>FH_Functions</b>, Section <b>FH_DO</b> (Digital Output), Peripheral <b>FH_DO02</b> (Digital Output 02)\n
  *       (The <b>DO02 (Digital Output 02)</b> could be any interested digital output of the micro-controller on which <b>FH</b> source code is ported)\n
  *
  * @note To have a clean code, <b>FH</b> user should have the implementation of the initialization, set and reset functions of the <b>Digital Output 02</b> in a separate c file\n
  *       Then <b>FH</b> user should include the header file <b>(.h)</b> of the related source file <b>(.c)</b> here\n
  *       This header file shall include the following items:\n
  *       The declaration of the initialization function of the <b>Digital Output 02</b>\n
  *       The declaration of the set and reset functions of the <b>Digital Output 02</b>
  *
  * @attention There are a total number of <b>4 attentions</b> (<b>FH</b> user defined code) in this file where <b>FH</b> user shall insert some code\n
  *            Other parts could be left intact
  *
  *******************************************************************************
  * SPDX-License-Identifier: Apache-2.0
 *
 * Copyright 2026 [Vahid Hasirchi]
 *
 * Licensed under the Apache License, Version 2.0 (the "License");
 * you may not use this file except in compliance with the License.
 * You may obtain a copy of the License at
 *
 * http://www.apache.org/licenses/LICENSE-2.0
 *
 * Unless required by applicable law or agreed to in writing, software
 * distributed under the License is distributed on an "AS IS" BASIS,
 * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
 * See the License for the specific language governing permissions and
 * limitations under the License.
  ********************************************************************************
  *
  @author Vahid Hasirchi (vahid.hasirchi@gmail.com)
  *
  * <b>For more information refer to FreeHIL.com</b>
  *
*/

And it indicates that there are 4 attentions in FH_DO02.c file
And these attentions are as following:

Attention 1 in FH_DO02.c file:

/* Primary Includes ------------------------------------------------------------------*/
// Attention 1: FH user defined code (include the mentioned header file here)

//

Attention 2 in FH_DO02.c file:

/**
 * @brief This function initializes the <b>Digital Output 02</b>\n
 *        The <b>Digital Output 02</b> could be any interested digital output of the micro-controller on which <b>FH</b> source code is ported\n
 *        <b>FH</b> user should call the initialization function of the interested digital output here
 *
 * @param  None
 * @return FH_ErrorInfo is returned
 *
 * @note
 * To have a clean code, just include the related header file\n
 * Then just call the function here
 *
 * @verbatim
    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    DO02
    &{Message}     =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DO}    Command=${DO_Commands_Init}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}

    Comments:

    DO02 => It indicates the Digital Output 02
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DO => It is the function in the message frame
    DO_Commands_Init => It is the command of the function in the message frame
  @endverbatim
 *
 *
 * @warning
 * To be able to set or reset the <b>Digital Output 02</b> of the micro-controller on which <b>FH</b> source code is ported, this function shall be invoked once by <b>RobotFramework</b> firstly\n
 * In other words, before invoking <b>FH_DO_SetStatus_DO02</b> function from <b>RobotFramework</b>, this function shall be invoked in order to initialize the digital output
 *
 * @author Vahid Hasirchi (vahid.hasirchi@gmail.com)
*/
FH_ErrorInfo FH_DO_Init_DO02()
{
    FH_ErrorInfo fh_ErrorInfo;    // Error Information
    FH_ResetErrorInfo(&fh_ErrorInfo);    // Reset Error Information to default

    // Attention 2: FH user defined code (call the initialization function of the Digital Output 02 here)

    // YourInitializationFunctionName ();

    //

    return fh_ErrorInfo;
}

Attention 3 and Attention 4 in FH_DO02.c file:

/**
 * @brief This function sets or resets the <b>Digital Output 02</b>\n
 *        The <b>Digital Output 02</b> could be any interested digital output of the micro-controller on which <b>FH</b> source code is ported\n
 *        <b>FH</b> user should call the set and reset functions of the interested digital output here
 *
 * @param  Status
 *         If Status is 1, the set function of the <b>Digital Output 02</b> shall be called\n
 *         If Status is 0, the reset function of the <b>Digital Output 02</b> shall be called
 * @return FH_ErrorInfo is returned
 *
 * @note
 * To have a clean code, just include the related header file\n
 * Then just call the function here
 *
 * @verbatim
    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    DO02    DO_Set
    &{Message}     =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DO}    Command=${DO_Commands_SetStatus}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}

    Comments:

    DO02 => It indicates the Digital Output 02
    DO_Set => It indicates the Digital Output 02 shall be Set (DO_Reset indicates the Digital Output 02 shall be Reset)
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DO => It is the function in the message frame
    DO_Commands_SetStatus => It is the command of the function in the message frame
  @endverbatim
 *
 *
 * @warning
 * To be able to set or reset the <b>Digital Output 02</b> of the micro-controller on which <b>FH</b> source code is ported, the <b>FH_DO_Init_DO02</b> function shall be invoked once by <b>RobotFramework</b> firstly\n
 * In other words, before invoking <b>FH_DO_SetStatus_DO02</b> function from <b>RobotFramework</b>, <b>FH_DO_Init_DO02</b> function shall be invoked in order to initialize the digital output
 *
 * @author Vahid Hasirchi (vahid.hasirchi@gmail.com)
*/
FH_ErrorInfo FH_DO_SetStatus_DO02(uint8_t Status)
{
    FH_ErrorInfo fh_ErrorInfo;    // Error Information
    FH_ResetErrorInfo(&fh_ErrorInfo);    // Reset Error Information to default

    if (Status == 1)    // If Status is 1, the set function of the Digital Output 02 shall be called
    {
        // Attention 3: FH user defined code (call the set function the Digital Output 02 here)

        // YourSetFunctionName();

        //
    }
    else if (Status == 0)    // If Status is 0, the reset function of the Digital Output 02 shall be called
    {
        // Attention 4: FH user defined code (call the reset function the Digital Output 02 here)

        // YourResetFunctionName();

        //
    }
    else
    {
        fh_ErrorInfo.error_code = FH_ERROR_MessageFrame;
    }

    return fh_ErrorInfo;
}

Attention: Even though there are 4 attentions (FH user defined code) in FH_DO02.c file, but in fact the FH user is simply faced with 4 simple code insertions as following:

1 - Including the related header file of DO02 (Digital Output 02) where the prototypes of Initialize, Set and Reset functions of DO02 (Digital Output 02) are defined (to have a clean code)
2 - Replacing YourInitializationFunctionName () with Initialize function just to initialize the DO02 (Digital Output 02)
3 - Replacing YourSetFunctionName () with Set function just to set the DO02 (Digital Output 02) to the logic 1 (Set)
4 - Replacing YourResetFunctionName () with Reset function just to reset the DO02 (Digital Output 02) to the logic 0 (Reset)

And then DO02 (Digital Output 02) is fully controllable from RobotFramework to be:
1 - Initialized
2 - Set
3 - Reset

And the point is the same scenario for the DO02 (Digital Output 02) could be quickly repeated for other interested digital outputs too

FH_Root

Attention: The FH user (who wants to develop a HIL simulator) could simply left all the data in FH_Root directory intact
In other words, there is no Attention (FH user defined code) in this directory

This directory includes the following directories:
1 - FH_General
2 - FH_Perif

FH_General

This directory includes the following directories:

1 - FH_ErrorInfo (Error Information)

To monitor different possible errors in different parts of the code

2 - FH_GeneralFunctions (General Functions)

All different possible general functions utilized in different parts of the code, go here

3 - FH_GlobalTimerCount (Global Timer Counter)

Attention

There are a diverse range of different situations where a precise timing is a necessity
To have a general heart beat (1 millisecond) for all different parts of the code, a timer in the micro-controller on which FH source code is ported, shall be utilized
FH_GlobalTimeCounter here shall be incremented every 1 millisecond in an interested timer ISR (Interrupt Service Routine) by FH user
For this to happen, FH_GlobalTimerCount.h shall be included in the interested timer ISR (Interrupt Service Routine) file

Here is an example of handling FH_GlobalTimeCounter in the Timer 4 of STM32CubeIDE with STM32H7B0VBT6 microcontroller:

/****************************************************************************************************
* Function name: HAL_TIM_PeriodElapsedCallback
* Entry parameters: htim - TIM_HandleTypeDef structure variable, which means the defined TIM (handle)
* Return value: None
* Function: Interrupt callback function (the timer generates an update interrupt)
* Note: This function will be called in TIM4_IRQHandler every 1 millisecond (the Timer 4 is already set for 1 millisecond interrupt)
****************************************************************************************************/
void HAL_TIM_PeriodElapsedCallback(TIM_HandleTypeDef *htim)
{
    if(htim == &htim4)    // If the callback is related to Timer 4
    {
        if (FH_GlobalTimeCounter >= 0xFFFFFFFF)    // If the FH_GlobalTimeCounter is reached to the maximum possible value
        {
            FH_GlobalTimeCounter = 0;    // Reset FH_GlobalTimeCounter
        }
        FH_GlobalTimeCounter++;    // Increase FH_GlobalTimeCounter by one
    }
}

FH_Perif (Peripherals)

This directory includes the following directories:

1 - FH_DO (Digital Output)

Including Cmd (commands) and FH_DO_Configs (Configurations) directories and also FH_DO.c and FH_DO.h files,
To handle commands related to DO01 (Digital Output 01) to DO64 (Digital Output 64)

2 - FH_DI (Digital Input)

Including Cmd (commands) and FH_DI_Configs (Configurations) directories and also FH_DI.c and FH_DI.h files,
To handle commands related to DI01 (Digital Input 01) to DI64 (Digital Input 64)

3 - FH_AO (Analog Output)

Including Cmd (commands) and FH_AO_Configs (Configurations) directories and also FH_AO.c and FH_AO.h files,
To handle commands related to AO01 (Analog Output 01) to AO64 (Analog Output 64)

4 - FH_AI (Analog Input)

Including Cmd (commands) and FH_AI_Configs (Configurations) directories and also FH_AI.c and FH_AI.h files,
To handle commands related to AI01 (Analog Input 01) to AI64 (Analog Input 64)

5 - FH_PWMO (PWM Output)

Including Cmd (commands) and FH_PWMO_Configs (Configurations) directories and also FH_PWMO.c and FH_PWMO.h files,
To handle commands related to PWMO01 (PWM Output 01) to PWMO64 (PWM Output 64)

6 - FH_PWMI (PWM Input)

Including Cmd (commands) and FH_PWMI_Configs (Configurations) directories and also FH_PWMI.c and FH_PWMI.h files,
To handle commands related to PWMI01 (PWM Input 01) to PWMI64 (PWM Input 64)

7 - FH_UART (UART)

Including Cmd (commands) and FH_UART_Configs (Configurations) directories and also FH_UART.c and FH_UART.h files,
To handle commands related to UART01 (UART 01) to UART08 (UART 08)

8 - FH_CAN (CAN)

Including Cmd (commands) and FH_CAN_Configs (Configurations) directories and also FH_CAN.c and FH_CAN.h files,
To handle commands related to CAN01 (CAN 01) to CAN08 (CAN 08)

FH_Setup

This directory includes the following directories:
1 - FH_DeviceAddress
2 - FH_DevicePeripherals
3 - FH_RFCommunication

FH_DeviceAddress ((Device Address))

Including FH_DeviceAddress.h (Device Address) file,
To set the device (or card) address here

The micro-controller on which FH source code is ported, could be simply utilized in a RS485 network
In other words, multiple devices or multiple cards could be simply utilized where every device or every card has its own address
Address of the device (or card) for every device (or card) is set here

Attention: FH_RFCommunication_Message is the structure for receiving the message frame from RobotFramework
The first data in this structure is the DeviceAddress
If a message (from RobotFramework) with a different DeviceAddress than the one set here is received, it will be ignored and not processed

Note: If there is just one device (or card), there is no need for the FH user to change the default address which is already 0x01
In this case, the address of the message in the message frame (in RobotFramework) shall be set to 01

FH_DevicePeripherals

Including FH_DevicePeripherals.h (Device Peripherals) file,
To set the the maximum number of peripherals for interested HIL Simulator here

Note: Regarding the limitations of the interested micro-controller on which FH source code is ported (Memory, Peripherals,...),
The number of the peripherals could be decreased to the minimum possible values

FH_RFCommunication (RobotFramework Communication)

Including the following files:

FH_RFCommunication_Configs.h (RobotFramework Communication Configuration)
FH_RFCommunication_GlobalVariables.h (RobotFramework Communication Global Variables)
FH_RFCommunication.c (RobotFramework Communication)
FH_RFCommunication.h (RobotFramework Communication)

To handle the communication between RobotFramework and the micro-controller on which FH source code is ported

The micro-controller on which FH source code is ported, could be simply utilized in a RS485 network
In other words, multiple devices or multiple cards could be simply utilized where every device or every card has its own address
Address of the device (or card) for every device (or card) is set by FH user in FH_DeviceAddress.h
An interested UART (called Communication Dedicated UART) by the FH user for the communication between RobotFramework and the micro-controller on which FH source code is ported, shall be dedicated

Note: To have a clean code, FH user should have the implementation of the initialization and send functions of the Communication Dedicated UART in a separate c file
Then FH user should include the header file (.h) of the related source file (.c) in FH_RFCommunication.c file
This header file shall include the following items:
The declaration of the initialization function of the Communication Dedicated UART
The declaration of the send function of the Communication Dedicated UART

Note: FH user shall use FH_RFCommunication_ReceiveBuf and FH_RFCommunication_ReceiveBufIndex in the receive ISR (Interrupt Service Routine) of the Communication Dedicated UART in a separate c file
For this to happen, FH user shall just include FH_RFCommunication_GlobalVariables.h there
In other word, FH_RFCommunication_ReceiveBuf array shall receive every byte of the received data there with FH_RFCommunication_ReceiveBufIndex as index of the array

Attention: There are a total number of 3 attentions (FH user defined code) in FH_RFCommunication.c file where FH user shall insert some code
Other parts could be left intact

Attention 1 in FH_RFCommunication.c file:

/* Includes ------------------------------------------------------------------*/
// Attention 1: FH user defined code (include the mentioned header file here)

//

Attention 2 in FH_RFCommunication.c file:

/**
 * @brief This function initializes the <b>Communication Dedicated UART</b>\n
 *        The <b>Communication Dedicated UART</b> could be any interested UART of the micro-controller on which <b>FH</b> source code is ported\n
 *        <b>FH</b> user should call the initialization function of the interested UART here
 *
 * @param  None
 *
 * @return FH_ErrorInfo is returned
 *
 * @note
 * To have a clean code, just include the related header file\n
 * Then just call the function here
 *
 * @warning
 * To be able to send or receive data through the <b>Communication Dedicated UART</b> of the micro-controller on which <b>FH</b> source code is ported, this function shall be invoked once in the <b>main.c</b> file firstly\n
 *
 * @author Vahid Hasirchi (vahid.hasirchi@gmail.com)
*/
FH_ErrorInfo FH_RFCommunication_Init ()
{
    FH_ErrorInfo fh_ErrorInfo;    // Error Information
    FH_ResetErrorInfo(&fh_ErrorInfo);    // Reset Error Information to default

    FH_RFCommunication_ReceiveBufIndex = 0;    // Reset FH_RFCommunication_ReceiveBufIndex

    // Attention 2: FH user defined code (call the initialization function of the Communication Dedicated UART here)

    // YourInitializationFunctionName ();

    //

    return fh_ErrorInfo;
}

Attention 3 in FH_RFCommunication.c file:

/**
 * @brief This function sends data through the <b>Communication Dedicated UART</b>\n
 *        The <b>Communication Dedicated UART</b> could be any interested UART of the micro-controller on which <b>FH</b> source code is ported\n
 *        <b>FH</b> user should call the send function of the interested UART here
 *
 * @param  DataString
 *         a null terminated string of data to be sent
 *
 * @return FH_ErrorInfo is returned
 *
 * @note
 * To have a clean code, just include the related header file\n
 * Then just call the function here
 *
 * @warning
 * To be able to send data through the <b>Communication Dedicated UART</b> of the micro-controller on which <b>FH</b> source code is ported, the <b>FH_RFCommunication_Init</b> function shall be invoked once in the <b>main.c</b> file firstly\n
 *
 * @author Vahid Hasirchi (vahid.hasirchi@gmail.com)
*/
FH_ErrorInfo FH_RFCommunication_Send (char* DataString)
{
    FH_ErrorInfo fh_ErrorInfo;    // Error Information
    FH_ResetErrorInfo(&fh_ErrorInfo);    // Reset Error Information to default

    // Attention 3: FH user defined code (call the send process function of the Communication Dedicated UART here with DataString as argument)
    // Hint: The prototype of the send process function should be something like YourSendProcessFunctionName(uint8_t* Data);

    // YourSendProcessFunctionName (DataString);

    //

    return fh_ErrorInfo;
}

Here is an example of handling FH_RFCommunication_ReceiveBuf and FH_RFCommunication_ReceiveBufIndex of the Communication Dedicated UART in the UART 1 of STM32H7B0VBT6 microcontroller:

/****************************************************************************************************
* Function name: HAL_UART_RxCpltCallback
* Entry parameters: huart - UART_HandleTypeDef structure variable, which means the defined UART (handle)
* Return value: None
* Function: Interrupt callback function (the uart generates an update interrupt)
* Note: This function will be called in UART1_IRQHandler for every byte of data received (the UART 1 is already set for receive interrupt)
****************************************************************************************************/
void HAL_UART_RxCpltCallback(UART_HandleTypeDef *huart)
{
    if(huart==(&huart1))    // If the callback is related to UART 1
    {
        FH_GlobalTimeCounter = 0;
        if (FH_RFCommunication_ReceiveBufIndex >= FH_RFCommunication_ReceiveBufLength)    // If the FH_RFCommunication_ReceiveBufIndex is reached to the maximum possible value
        {
            FH_RFCommunication_ReceiveBufIndex = 0;    // Reset FH_RFCommunication_ReceiveBufIndex
        }
        do
        {
        } while (HAL_OK != HAL_UART_Receive_IT(&huart1, Receive_Data_1, 1));    // Get the received data in Receive_Data_1
        FH_RFCommunication_ReceiveBuf[FH_RFCommunication_ReceiveBufIndex++] = Receive_Data_1[0];    // Transfer the received byte to FH_RFCommunication_ReceiveBuf and increase FH_RFCommunication_ReceiveBufIndex
    }
}

FH RobotFramework source code (HIL simulator computer side)

Remarks: Test Automation is a testing approach where the execution of the test cases is automated with the executing different test cases automatically without human intervention
There are different Test Automation frameworks like RobotFramework which is an open source framework to automatically handle the execution of different test cases
RobotFramework is a generic software test automation framework for acceptance testing and acceptance test-driven development (ATDD)

There are 2 main directories in FH RobotFramework source code (FH_RobotFramework) as following:

1 - FH_Resources

Including FH_Keywords.robot file and FH_MessageSetting.robot file

FH_Keywords.robot:
Just the SendMessage function used in TestCategoty1.robot file is defined here as keyword

FH_MessageSetting.robot:
Just the variables used in TestCategoty1.robot file are defined here (like ${ERROR_NoInfo},${DeviceAddress_01},{Function_DO},${DO_Commands_Init},....)

2 - FH_TestSuites

Including TestSuite1 (Test suite 1) directory which includes TestCategoty1.robot file

TestCategoty1.robot:
This is the main file where the FH user (who wants to develop a HIL simulator) could write test cases

FH RobotFramework source code utilizes the Serial library in RobotFramework
The FH user (who wants to develop a HIL simulator) could simply send different messages to the microcontroller on which FH Embedded Software source code is ported and verify the result too

Note: An interface provides the communication between FH RobotFramework source code in HIL simulator computer side and FH Embedded Software source code in HIL simulator hardware side
The most simple interface is a USB to Serial interface which could connect the computer to one HIL simulator (device or card with a unique predefined address)
Another interface is a USB to Serial with RS485 interface which could connect the computer to several HIL simulators (devices or cards with unique predefined addresses)

Here is an example of setting the Digital Output Number 01 of an interested microcontroller to logic 1 (Set):

==============================================================================
                      ##### RobotFramework Example #####
==============================================================================
@{MessageData} =    Create List    ${DO01}    ${DO_Set}
&{Message}     =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DO}    Command=${DO_Commands_SetStatus}    Data=@{MessageData}
${Result}    SendMessage    &{Message}

Comments:

DO01 => It indicates the Digital Output 01
DO_Set => It indicates the Digital Output 01 shall be Set (DO_Reset indicates the Digital Output 01 shall be Reset)
DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
Function_DO => It is the function in the message frame
DO_Commands_SetStatus => It is the command of the function in the message frame

The following HIL simulator's peropherals are supported:
1 - Up to 64 Digital Output
2 - Up to 64 Digital Input
3 - Up to 64 Analog Output
4 - Up to 64 Analog Input
5 - Up to 64 PWM Output
6 - Up to 64 PWM Input
7 - Up to 8 UART (TX/RX)
8 - Up to 8 CAN (TX/RX)

DO (Digital Output) Messages

Message	Description
DO_Commands_Init	Initializes a DO (Digital Output)
DO_Commands_SetStatus	Sets the status of a DO (Digital Output) to 1 or 0
DO_Commands_InitMULTI	Initializes up to 64 DO (Digital Output)
DO_Commands_SetStatusMULTI	Sets the status of up to 64 DO (Digital Output)

DO_Commands_Init

This command initializes a DO (Digital Output)
This command may invoke FH_DO_Init_DO01 to FH_DO_Init_DO64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_DO (0x00)
Command	DO_Commands_Init (0x00)
MessageDataLength	1 byte (0x01)
MessageData	Digital Output Number (0x01 for DO01 to 0x40 for DO64)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"DO"
Command (4 bytes)	"Init"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${DO01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DO}    Command=${DO_Commands_Init}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    DO
    Should Be Equal    ${ResultComponents}[2]    Init
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    DO01 => It indicates the Digital Output 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DO => It is the function in the message frame
    DO_Commands_Init => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|DO|Init|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = DO
    Log Many    Command =    ${ResultComponents}[2] => Command = Init
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    DO => If ${ResultComponents}[1] (Function) is not equal to "DO" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Init => If ${ResultComponents}[2] (Command) is not equal to "Init" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

DO_Commands_SetStatus

This command sets the status of a DO (Digital Output) to 1 or 0
This command may invoke FH_DO_SetStatus_DO01 to FH_DO_SetStatus_DO64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_DO (0x00)
Command	DO_Commands_SetStatus (0x01)
MessageDataLength	2 bytes (0x02)
MessageData1	Digital Output Number (0x01 for Digital Output Number 01 to 0x40 for Digital Output Number 64)
MessageData2	DO_Set (0x01 for status as 1) or DO_Reset (0x00 to set status as 0)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"DO"
Command (9 bytes)	"SetStatus"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${DO01}    ${DO_Set}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DO}    Command=${DO_Commands_SetStatus}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    DO
    Should Be Equal    ${ResultComponents}[2]    SetStatus
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    DO01 => It indicates the Digital Output 01
    DO_Set => It indicates the Digital Output 01 shall be Set (DO_Reset indicates the Digital Output 01 shall be Reset)
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DO => It is the function in the message frame
    DO_Commands_SetStatus => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|DO|SetStatus|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = DO
    Log Many    Command =    ${ResultComponents}[2] => Command = SetStatus
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    DO => If ${ResultComponents}[1] (Function) is not equal to "DO" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    SetStatus => If ${ResultComponents}[2] (Command) is not equal to "SetStatus" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

DO_Commands_InitMULTI

This command initializes up to 64 DO (Digital Output)
This command may invoke FH_DO_Init_DO01 to FH_DO_Init_DO64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_DO (0x00)
Command	DO_Commands_InitMULTI (0x02)
MessageDataLength	8 bytes (0x08)
MessageData1	Digital Output Number Byte 1 for DO01 to DO08 (Example:0x82 => DO01 and DO07 should be initialized)
MessageData2	Digital Output Number Byte 2 for DO09 to DO16 (Example:0x82 => DO09 and DO15 should be initialized)
MessageData3	Digital Output Number Byte 3 for DO17 to DO24 (Example:0x82 => DO17 and DO23 should be initialized)
MessageData4	Digital Output Number Byte 4 for DO25 to DO32 (Example:0x82 => DO25 and DO31 should be initialized)
MessageData5	Digital Output Number Byte 5 for DO33 to DO40 (Example:0x82 => DO33 and DO39 should be initialized)
MessageData6	Digital Output Number Byte 6 for DO41 to DO48 (Example:0x82 => DO41 and DO47 should be initialized)
MessageData7	Digital Output Number Byte 7 for DO49 to DO56 (Example:0x82 => DO49 and DO55 should be initialized)
MessageData8	Digital Output Number Byte 8 for DO57 to DO64 (Example:0x82 => DO57 and DO63 should be initialized)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"DO"
Command (9 bytes)	"InitMULTI"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    FF    FF    FF    FF    FF    FF    FF    FF
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DO}    Command=${DO_Commands_InitMULTI}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    DO
    Should Be Equal    ${ResultComponents}[2]    InitMULTI
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    FF    FF    FF    FF    FF    FF    FF    FF => Example data as the first 8 parameters of the Data in the message frame utilized as mask (In this example it means all 64 digital outputs shall be initialized)
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DO => It is the function in the message frame
    DO_Commands_InitMULTI => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|DO|InitMULTI|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = DO
    Log Many    Command =    ${ResultComponents}[2] => Command = InitMULTI
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    DO => If ${ResultComponents}[1] (Function) is not equal to "DO" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    InitMULTI => If ${ResultComponents}[2] (Command) is not equal to "InitMULTI" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

DO_Commands_SetStatusMULTI

This command sets the status of up to 64 DO (Digital Output)
This command may invoke FH_DO_SetStatus_DO01 to FH_DO_SetStatus_DO64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_DO (0x00)
Command	DO_Commands_SetStatusMULTI (0x03)
MessageDataLength	16 bytes (0x10)
MessageData1	Digital Output Number Mask Byte 1 for DO01 to DO08 (Example:0x82 => DO01 and DO07 should be set or reset)
MessageData2	Digital Output Number Mask Byte 2 for DO09 to DO16 (Example:0x82 => DO09 and DO15 should be set or reset)
MessageData3	Digital Output Number Mask Byte 3 for DO17 to DO24 (Example:0x82 => DO17 and DO23 should be set or reset)
MessageData4	Digital Output Number Mask Byte 4 for DO25 to DO32 (Example:0x82 => DO25 and DO31 should be set or reset)
MessageData5	Digital Output Number Mask Byte 5 for DO33 to DO40 (Example:0x82 => DO33 and DO39 should be set or reset)
MessageData6	Digital Output Number Mask Byte 6 for DO41 to DO48 (Example:0x82 => DO41 and DO47 should be set or reset)
MessageData7	Digital Output Number Mask Byte 7 for DO49 to DO56 (Example:0x82 => DO49 and DO55 should be set or reset)
MessageData8	Digital Output Number Mask Byte 8 for DO57 to DO64 (Example:0x82 => DO57 and DO63 should be set or reset)
MessageData9	Digital Output Number Status Byte 1 for DO01 to DO08 (Example:0x80 => DO01 should be set and DO07 should be reset)
MessageData10	Digital Output Number Status Byte 2 for DO09 to DO16 (Example:0x80 => DO09 should be set and DO15 should be reset)
MessageData11	Digital Output Number Status Byte 3 for DO17 to DO24 (Example:0x80 => DO17 should be set and DO23 should be reset)
MessageData12	Digital Output Number Status Byte 4 for DO25 to DO32 (Example:0x80 => DO25 should be set and DO31 should be reset)
MessageData13	Digital Output Number Status Byte 5 for DO33 to DO40 (Example:0x80 => DO33 should be set and DO39 should be reset)
MessageData14	Digital Output Number Status Byte 6 for DO41 to DO48 (Example:0x80 => DO41 should be set and DO47 should be reset)
MessageData15	Digital Output Number Status Byte 7 for DO49 to DO56 (Example:0x80 => DO49 should be set and DO55 should be reset)
MessageData16	Digital Output Number Status Byte 8 for DO57 to DO64 (Example:0x80 => DO57 should be set and DO63 should be reset)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"DO"
Command (14 bytes)	"SetStatusMULTI"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    FF    FF    FF    FF    FF    FF    FF    FF    01    02    03    04    05    06    07    08
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DO}    Command=${DO_Commands_SetStatusMULTI}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal As Strings    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    DO
    Should Be Equal    ${ResultComponents}[2]    SetStatusMULTI
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    FF    FF    FF    FF    FF    FF    FF    FF => Example data as the first 8 parameters of the Data in the message frame utilized as mask (In this example it means all 64 digital outputs shall set status)
    01    02    03    04    05    06    07    08 => Example data as the second 8 parameters of the Data in the message frame as data value of 1 or 0, corresponding to the first 8 bytes)
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DO => It is the function in the message frame
    DO_Commands_SetStatusMULTI => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|DO|SetStatusMULTI|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = DO
    Log Many    Command =    ${ResultComponents}[2] => Command = SetStatusMULTI
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    DO => If ${ResultComponents}[1] (Function) is not equal to "DO" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    SetStatusMULTI => If ${ResultComponents}[2] (Command) is not equal to "SetStatusMULTI" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

DI (Digital Input) Messages

Message	Description
DI_Commands_Init	Initializes a DI (Digital Input)
DI_Commands_GetStatus	Gets the status of a DI (Digital Input) as 1 or 0
DI_Commands_InitMULTI	Initializes up to 64 DI (Digital Input)
DI_Commands_GetStatusMULTI	Gets the status of up to 64 DI (Digital Input)

DI_Commands_Init

This command initializes a DI (Digital Input)
This command may invoke FH_DI_Init_DI01 to FH_DI_Init_DI64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_DI (0x01)
Command	DI_Commands_Init (0x00)
MessageDataLength	1 byte (0x01)
MessageData	Digital Input Number (0x01 for DI01 to 0x40 for DI64)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"DI"
Command (4 bytes)	"Init"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${DI01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DI}    Command=${DI_Commands_Init}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    DI
    Should Be Equal    ${ResultComponents}[2]    Init
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    DI01 => It indicates the Digital Input 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DI => It is the function in the message frame
    DI_Commands_Init => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|DI|Init|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = DI
    Log Many    Command =    ${ResultComponents}[2] => Command = Init
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    DI => If ${ResultComponents}[1] (Function) is not equal to "DI" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Init => If ${ResultComponents}[2] (Command) is not equal to "Init" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

DI_Commands_GetStatus

This command gets the status of a DI (Digital Input) as 1 or 0
This command may invoke FH_DI_GetStatus_DI01 to FH_DI_GetStatus_DI64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_DI (0x01)
Command	DI_Commands_GetStatus (0x01)
MessageDataLength	1 byte (0x01)
MessageData	Digital Input Number (0x01 for DI01 to 0x40 for DI64)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"DI"
Command (9 bytes)	"GetStatus"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (1 byte)	"0" or "1" (as status)

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${DI01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DI}    Command=${DI_Commands_GetStatus}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    Status =    ${ResultComponents}[4]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    DI
    Should Be Equal    ${ResultComponents}[2]    GetStatus
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}
    Should Be Equal    ${ResultComponents}[4]    0

    Comments:

    DI01 => It indicates the Digital Input 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DI => It is the function in the message frame
    DI_Commands_GetStatus => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|DI|GetStatus|00|0
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = DI
    Log Many    Command =    ${ResultComponents}[2] => Command = GetStatus
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    DI => If ${ResultComponents}[1] (Function) is not equal to "DI" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    GetStatus => If ${ResultComponents}[2] (Command) is not equal to "GetStatus" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    0 =>  If ${ResultComponents}[4] (Status) is not equal to "0" then the test is not passed

DI_Commands_InitMULTI

This command initializes up to 64 DI (Digital Input)
This command may invoke FH_DI_Init_DI01 to FH_DI_Init_DI64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_DI (0x01)
Command	DI_Commands_InitMULTI (0x02)
MessageDataLength	8 bytes (0x08)
MessageData1	Digital Input Number Byte 1 for DI01 to DI08 (Example:0x82 => DI01 and DI07)
MessageData2	Digital Input Number Byte 2 for DI09 to DI16 (Example:0x82 => DI09 and DI15)
MessageData3	Digital Input Number Byte 3 for DI17 to DI24 (Example:0x82 => DI17 and DI23)
MessageData4	Digital Input Number Byte 4 for DI25 to DI32 (Example:0x82 => DI25 and DI31)
MessageData5	Digital Input Number Byte 5 for DI33 to DI40 (Example:0x82 => DI33 and DI39)
MessageData6	Digital Input Number Byte 6 for DI41 to DI48 (Example:0x82 => DI41 and DI47)
MessageData7	Digital Input Number Byte 7 for DI49 to DI56 (Example:0x82 => DI49 and DI55)
MessageData8	Digital Input Number Byte 8 for DI57 to DI64 (Example:0x82 => DI57 and DI63)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"DI"
Command (9 bytes)	"InitMULTI"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    FF    FF    FF    FF    FF    FF    FF    FF
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DI}    Command=${DI_Commands_InitMULTI}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    DI
    Should Be Equal    ${ResultComponents}[2]    InitMULTI
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    FF    FF    FF    FF    FF    FF    FF    FF => Example data as the first 8 parameters
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DI => It is the function in the message frame
    DI_Commands_InitMULTI => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|DI|InitMULTI|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = DI
    Log Many    Command =    ${ResultComponents}[2] => Command = InitMULTI
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    DI => If ${ResultComponents}[1] (Function) is not equal to "DI" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    InitMULTI => If ${ResultComponents}[2] (Command) is not equal to "InitMULTI" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

DI_Commands_GetStatusMULTI

This command gets the status of up to 64 DI (Digital Input)
This command may invoke FH_DI_GetStatus_DI01 to FH_DI_GetStatus_DI64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_DI (0x01)
Command	DI_Commands_GetStatusMULTI (0x03)
MessageDataLength	8 bytes (0x08)
MessageData1	Digital Input Number Byte 1 for DI01 to DI08 (Example:0x82 => Get Status of DI01 and DI07)
MessageData2	Digital Input Number Byte 2 for DI09 to DI16 (Example:0x82 => Get Status of DI09 and DI15)
MessageData3	Digital Input Number Byte 3 for DI17 to DI24 (Example:0x82 => Get Status of DI17 and DI23)
MessageData4	Digital Input Number Byte 4 for DI25 to DI32 (Example:0x82 => Get Status of DI25 and DI31)
MessageData5	Digital Input Number Byte 5 for DI33 to DI40 (Example:0x82 => Get Status of DI33 and DI39)
MessageData6	Digital Input Number Byte 6 for DI41 to DI48 (Example:0x82 => Get Status of DI41 and DI47)
MessageData7	Digital Input Number Byte 7 for DI49 to DI56 (Example:0x82 => Get Status of DI49 and DI55)
MessageData8	Digital Input Number Byte 8 for DI57 to DI64 (Example:0x82 => Get Status of DI57 and DI63)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"DI"
Command (14 bytes)	"GetStatusMULTI"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of Digital Input Status Byte 1 for DI01 to DI08 (Example:"80" => DI01 is 1 and DI07 is 0)
MessageData3 (2 bytes)	Ascii equivalent of the hex value of Digital Input Status Byte 2 for DI09 to DI16 (Example:"80" => DI09 is 1 and DI15 is 0)
MessageData4 (2 bytes)	Ascii equivalent of the hex value of Digital Input Status Byte 3 for DI17 to DI24 (Example:"80" => DI17 is 1 and DI23 is 0)
MessageData5 (2 bytes)	Ascii equivalent of the hex value of Digital Input Status Byte 4 for DI25 to DI32 (Example:"80" => DI25 is 1 and DI31 is 0)
MessageData6 (2 bytes)	Ascii equivalent of the hex value of Digital Input Status Byte 5 for DI33 to DI40 (Example:"80" => DI33 is 1 and DI39 is 0)
MessageData7 (2 bytes)	Ascii equivalent of the hex value of Digital Input Status Byte 6 for DI41 to DI48 (Example:"80" => DI41 is 1 and DI47 is 0)
MessageData8 (2 bytes)	Ascii equivalent of the hex value of Digital Input Status Byte 7 for DI49 to DI56 (Example:"80" => DI49 is 1 and DI55 is 0)
MessageData9 (2 bytes)	Ascii equivalent of the hex value of Digital Input Status Byte 8 for DI57 to DI64 (Example:"80" => DI57 is 1 and DI63 is 0)

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    FF    FF    FF    FF    FF    FF    FF    FF
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DI}    Command=${DI_Commands_GetStatusMULTI}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    Status =    ${ResultComponents}[4]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    DI
    Should Be Equal    ${ResultComponents}[2]    GetStatusMULTI
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}
    Should Be Equal    ${ResultComponents}[4]    0011001100220022

    Comments:

    FF    FF    FF    FF    FF    FF    FF    FF => Example data as the first 8 parameters
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DI => It is the function in the message frame
    DI_Commands_GetStatusMULTI => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|DI|GetStatusMULTI|00|0011001100220022
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = DI
    Log Many    Command =    ${ResultComponents}[2] => Command = GetStatusMULTI
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    DI => If ${ResultComponents}[1] (Function) is not equal to "DI" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    GetStatusMULTI => If ${ResultComponents}[2] (Command) is not equal to "GetStatusMULTI" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    0011001100220022 => If ${ResultComponents}[4] (Status) is not equal to "0011001100220022" then the test is not passed

AO (Analog Output) Messages

Message

Description

AO_Commands_Init

Initializes a AO (Analog Output)

AO_Commands_SetStatus

Sets the status of a AO (Analog Output)

AO_Commands_Init

This command initializes a AO (Analog Output)
This command may invoke FH_AO_Init_AO01 to FH_AO_Init_AO64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_AO (0x02)
Command	AO_Commands_Init (0x00)
MessageDataLength	1 byte (0x01)
MessageData	Analog Output Number (0x01 for AO01 to 0x40 for AO64)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"AO"
Command (4 bytes)	"Init"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${AO01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_AO}    Command=${AO_Commands_Init}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    AO
    Should Be Equal    ${ResultComponents}[2]    Init
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    AO01 => It indicates the Analog Output 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_AO => It is the function in the message frame
    AO_Commands_Init => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|AO|Init|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = AO
    Log Many    Command =    ${ResultComponents}[2] => Command = Init
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    AO => If ${ResultComponents}[1] (Function) is not equal to "AO" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Init => If ${ResultComponents}[2] (Command) is not equal to "Init" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

AO_Commands_SetStatus

This command sets the status of a AO (Analog Output))
This command may invoke FH_AO_SetStatus_AO01 to FH_AO_SetStatus_AO64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_AO (0x02)
Command	AO_Commands_SetStatus (0x01)
MessageDataLength	5 bytes (0x05)
MessageData1	Analog Output Number (0x01 for Analog Output Number 01 to 0x40 for Analog Output Number 64)
MessageData2	Analog value Byte 4
MessageData3	Analog value Byte 3
MessageData4	Analog value Byte 2
MessageData5	Analog value Byte 1
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"AO"
Command (9 bytes)	"SetStatus"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${AO01}    F1    C2    01    08
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_AO}    Command=${AO_Commands_SetStatus}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    AO
    Should Be Equal    ${ResultComponents}[2]    SetStatus
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    AO01 => It indicates the Analog Output 01
    F1    C2    01    08 => Example data as analog value (0xF1C20108) to be set through the <b>Analog Output 01</b>\n
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_AO => It is the function in the message frame
    AO_Commands_SetStatus => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|AO|SetStatus|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = AO
    Log Many    Command =    ${ResultComponents}[2] => Command = SetStatus
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    AO => If ${ResultComponents}[1] (Function) is not equal to "AO" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    SetStatus => If ${ResultComponents}[2] (Command) is not equal to "SetStatus" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

AI (Analog Input) Messages

Message

Description

AI_Commands_Init

Initializes a AI (Analog Input)

AI_Commands_GetStatus

Gets the status of a AI (Analog Input) as 1 or 0

AI_Commands_Init

This command initializes a AI (Analog Input)
This command may invoke FH_AI_Init_AI01 to FH_AI_Init_AI64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_AI (0x03)
Command	AI_Commands_Init (0x00)
MessageDataLength	1 byte (0x01)
MessageData	Analog Input Number (0x01 for AI01 to 0x40 for AI64)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"AI"
Command (4 bytes)	"Init"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${AI01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_AI}    Command=${AI_Commands_Init}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    AI
    Should Be Equal    ${ResultComponents}[2]    Init
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    AI01 => It indicates the Analog Input 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_AI => It is the function in the message frame
    AI_Commands_Init => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|AI|Init|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = AI
    Log Many    Command =    ${ResultComponents}[2] => Command = Init
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    AI => If ${ResultComponents}[1] (Function) is not equal to "AI" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Init => If ${ResultComponents}[2] (Command) is not equal to "Init" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

AI_Commands_GetStatus

This command gets the status of a AI (Analog Input) as 1 or 0
This command may invoke FH_AI_GetStatus_AI01 to FH_AI_GetStatus_AI64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_AI (0x03)
Command	AI_Commands_GetStatus (0x01)
MessageDataLength	1 byte (0x01)
MessageData	Analog Input Number (0x01 for AI01 to 0x40 for AI64)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"AI"
Command (9 bytes)	"GetStatus"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of the analog value byte 4
MessageData3 (2 bytes)	Ascii equivalent of the hex value of the analog value byte 3
MessageData4 (2 bytes)	Ascii equivalent of the hex value of the analog value byte 2
MessageData5 (2 bytes)	Ascii equivalent of the hex value of the analog value byte 1

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${AI01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_AI}    Command=${AI_Commands_GetStatus}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    Status =    ${ResultComponents}[4]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    AI
    Should Be Equal    ${ResultComponents}[2]    GetStatus
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}
    Should Be Equal    ${ResultComponents}[4]    00110011

    Comments:

    AI01 => It indicates the Analog Input 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_AI => It is the function in the message frame
    AI_Commands_GetStatus => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|AI|GetStatus|00|00110011
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = AI
    Log Many    Command =    ${ResultComponents}[2] => Command = GetStatus
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    AI => If ${ResultComponents}[1] (Function) is not equal to "AI" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    GetStatus => If ${ResultComponents}[2] (Command) is not equal to "GetStatus" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    00110011 => If ${ResultComponents}[4] (Status) is not equal to "00110011" then the test is not passed

PWMO (PWM Output) Messages

Message

Description

PWMO_Commands_Init

Initializes a PWMO (PWM Output)

PWMO_Commands_SetStatus

Sets the status of a PWMO (PWM Output)

PWMO_Commands_Init

This command initializes a PWMO (PWM Output)
This command may invoke FH_PWMO_Init_PWMO01 to FH_PWMO_Init_PWMO64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_PWMO (0x04)
Command	PWMO_Commands_Init (0x00)
MessageDataLength	1 byte (0x01)
MessageData	PWM Output Number (0x01 for PWMO01 to 0x40 for PWMO64)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"PWMO"
Command (4 bytes)	"Init"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${PWMO01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_PWMO}    Command=${PWMO_Commands_Init}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    PWMO
    Should Be Equal    ${ResultComponents}[2]    Init
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    PWMO01 => It indicates the PWM Output 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_PWMO => It is the function in the message frame
    PWMO_Commands_Init => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|PWMO|Init|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = PWMO
    Log Many    Command =    ${ResultComponents}[2] => Command = Init
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    PWMO => If ${ResultComponents}[1] (Function) is not equal to "PWMO" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Init => If ${ResultComponents}[2] (Command) is not equal to "Init" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

PWMO_Commands_SetStatus

This command sets the status of a PWMO (PWM Output))
This command may invoke FH_PWMO_SetStatus_PWMO01 to FH_PWMO_SetStatus_PWMO64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_PWMO (0x04)
Command	PWMO_Commands_SetStatus (0x01)
MessageDataLength	6 bytes (0x06)
MessageData1	PWM Output Number (0x01 for PWM Output Number 01 to 0x40 for PWM Output Number 64)
MessageData2	PWM frequency value Byte 4
MessageData3	PWM frequency value Byte 3
MessageData4	PWM frequency value Byte 2
MessageData5	PWM frequency value Byte 1
MessageData6	PWM duty cycle value
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"PWMO"
Command (9 bytes)	"SetStatus"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${PWMO01}    00    00    00    F0    32
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_PWMO}    Command=${PWMO_Commands_SetStatus}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    PWMO
    Should Be Equal    ${ResultComponents}[2]    SetStatus
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}
    Comments:

    PWMO01 => It indicates the PWM Output 01
    00    00    00    F0 => Example data as PWM frequency (0x000000F0) to be set through the <b>PWM Output 01</b>\n
    32 => Example data as PWM duty cycle (0x32 => as 50% duty cycle) to be set through the <b>PWM Output 01</b>\n
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_PWMO => It is the function in the message frame
    PWMO_Commands_SetStatus => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|PWMO|SetStatus|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = PWMO
    Log Many    Command =    ${ResultComponents}[2] => Command = SetStatus
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    PWMO => If ${ResultComponents}[1] (Function) is not equal to "PWMO" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    SetStatus => If ${ResultComponents}[2] (Command) is not equal to "SetStatus" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

PWMI (PWM Input) Messages

Message

Description

PWMI_Commands_Init

Initializes a PWMI (PWM Input)

PWMI_Commands_GetStatus

Gets the status of a PWMI (PWM Input) as 1 or 0

PWMI_Commands_Init

This command initializes a PWMI (PWM Input)
This command may invoke FH_PWMI_Init_PWMI01 to FH_PWMI_Init_PWMI64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_PWMI (0x05)
Command	PWMI_Commands_Init (0x00)
MessageDataLength	1 byte (0x01)
MessageData	PWM Input Number (0x01 for PWMI01 to 0x40 for PWMI64)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"PWMI"
Command (4 bytes)	"Init"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${PWMI01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_PWMI}    Command=${PWMI_Commands_Init}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    PWMI
    Should Be Equal    ${ResultComponents}[2]    Init
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    PWMI01 => It indicates the PWM Input 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_PWMI => It is the function in the message frame
    PWMI_Commands_Init => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|PWMI|Init|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = PWMI
    Log Many    Command =    ${ResultComponents}[2] => Command = Init
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    PWMI => If ${ResultComponents}[1] (Function) is not equal to "PWMI" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Init => If ${ResultComponents}[2] (Command) is not equal to "Init" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

PWMI_Commands_GetStatus

This command gets the status of a PWMI (PWM Input) as 1 or 0
This command may invoke FH_PWMI_GetStatus_PWMI01 to FH_PWMI_GetStatus_PWMI64

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_PWMI (0x05)
Command	PWMI_Commands_GetStatus (0x01)
MessageDataLength	1 byte (0x01)
MessageData	PWM Input Number (0x01 for PWMI01 to 0x40 for PWMI64)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"PWMI"
Command (9 bytes)	"GetStatus"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of the PWM frequency value byte 4
MessageData3 (2 bytes)	Ascii equivalent of the hex value of the PWM frequency value byte 3
MessageData4 (2 bytes)	Ascii equivalent of the hex value of the PWM frequency value byte 2
MessageData5 (2 bytes)	Ascii equivalent of the hex value of the PWM frequency value byte 1
MessageData6 (2 bytes)	Ascii equivalent of the hex value of the PWM duty cycle

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${PWMI01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_PWMI}    Command=${PWMI_Commands_GetStatus}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    Frequency =    ${ResultComponents}[4]
    Log Many    Duty Cycle =    ${ResultComponents}[5]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    PWMI
    Should Be Equal    ${ResultComponents}[2]    GetStatus
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}
    Should Be Equal    ${ResultComponents}[4]    00110011
    Should Be Equal    ${ResultComponents}[5]    32

    Comments:

    PWMI01 => It indicates the PWM Input 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_PWMI => It is the function in the message frame
    PWMI_Commands_GetStatus => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|PWMI|GetStatus|00|00110011|32
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = PWMI
    Log Many    Command =    ${ResultComponents}[2] => Command = GetStatus
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    PWMI => If ${ResultComponents}[1] (Function) is not equal to "PWMI" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    GetStatus => If ${ResultComponents}[2] (Command) is not equal to "GetStatus" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    00110011 => If ${ResultComponents}[4] (Frequency) is not equal to "00110011" then the test is not passed
    Should Be Equal    ${ResultComponents}[5]    32 => If ${ResultComponents}[5] (Duty cycle) is not equal to "32" then the test is not passed

UART Messages

Message	Description
UART_Commands_Init	Initializes a UART
UART_Commands_Send	Sends data through the UART
UART_Commands_Receive	Retrieves the ISR (Interrupt Service Routine) receive buffer of the UART
UART_Commands_ReceiveW	Waits to receive the specified number of bytes of data through the ISR (Interrupt Service Routine) receive buffer of the UART
UART_Commands_ResetRB	Resets the ISR (Interrupt Service Routine) receive buffer index of the UART
UART_Commands_SSD8	Sets the shared data buffer (8 bit buffer) of the UART
UART_Commands_SSD16	Sets the shared data buffer (16 bit buffer) of the UART
UART_Commands_SSD32	Sets the shared data buffer (32 bit buffer) of the UART
UART_Commands_GSSD8	Gets the shared data buffer (8 bit buffer) of the UART
UART_Commands_GSD16	Gets the shared data buffer (16 bit buffer) of the UART
UART_Commands_GSD32	Gets the shared data buffer (32 bit buffer) of the UART

UART_Commands_Init

This command initializes a UART
This command may invoke FH_UART_Init_UART01 to FH_UART_Init_UART08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_UART (0x06)
Command	UART_Commands_Init (0x00)
MessageDataLength	1 byte (0x01)
MessageData	UART Number (0x01 for UART01 to 0x08 for UART08)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"UART"
Command (4 bytes)	"Init"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${UART01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_UART}    Command=${UART_Commands_Init}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    UART
    Should Be Equal    ${ResultComponents}[2]    Init
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    UART01 => It indicates the UART 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_UART => It is the function in the message frame
    UART_Commands_Init => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|UART|Init|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = UART
    Log Many    Command =    ${ResultComponents}[2] => Command = Init
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    UART => If ${ResultComponents}[1] (Function) is not equal to "UART" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Init => If ${ResultComponents}[2] (Command) is not equal to "Init" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

UART_Commands_Send

This command sends data through the UART
This command may invoke FH_UART_Send_UART01 to FH_UART_Send_UART08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_UART (0x06)
Command	UART_Commands_Send (0x01)
MessageDataLength	N bytes (Example: N = 5 => 0x05)
MessageData1	UART Number (0x01 for UART01 to 0x08 for UART08)
MessageData2	Length of the data to be sent
MessageData3	Data byte1 to be sent
MessageData...	Data byte... to be sent
MessageDataN	Data byteN to be sent
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"UART"
Command (4 bytes)	"Send"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${UART01}    02    B1    FF
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_UART}    Command=${UART_Commands_Send}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    UART
    Should Be Equal    ${ResultComponents}[2]    Send
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    UART01 => It indicates the UART 01
    02 => Example length of the data to be sent
    B1     FF => Example data (0xB1, 0xFF) to be sent (or apart from the data to be sent, it may include some other data like ID, Filter, ... to be processed too, if need be) through the <b>UART 01</b>\n
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_UART => It is the function in the message frame
    UART_Commands_Send => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|UART|Send|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = UART
    Log Many    Command =    ${ResultComponents}[2] => Command = Send
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    UART => If ${ResultComponents}[1] (Function) is not equal to "UART" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Send => If ${ResultComponents}[2] (Command) is not equal to "Send" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

UART_Commands_Receive

This function retrieves the ISR (Interrupt Service Routine) receive buffer of the UART
This command may invoke FH_UART_Receive_UART01 to FH_UART_Receive_UART08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_UART (0x06)
Command	UART_Commands_Receive (0x02)
MessageDataLength	1 byte (0x01)
MessageData	UART Input Number (0x01 for UART01 to 0x08 for UART08)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"UART"
Command (7 bytes)	"Receive"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of the UART receive buffer index value (Length of the received data)
MessageData3 (2 bytes)	Ascii equivalent of the hex value of the UART receive buffer value byte 1
MessageData... (2 bytes)	Ascii equivalent of the hex value of the UART receive buffer value byte ...
MessageDataN (2 bytes)	Ascii equivalent of the hex value of the UART receive buffer value byte N

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${UART01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_UART}    Command=${UART_Commands_Receive}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    DataLength =    ${ResultComponents}[4]
    Log Many    Data =    ${ResultComponents}[5]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    UART
    Should Be Equal    ${ResultComponents}[2]    Receive
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}
    Should Be Equal    ${ResultComponents}[4]    04
    Should Be Equal    ${ResultComponents}[5]    ABCDabcd

    Comments:

    UART01 => It indicates the UART 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_UART => It is the function in the message frame
    UART_Commands_Receive => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|UART|Receive|00|04|ABCDabcd
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = UART
    Log Many    Command =    ${ResultComponents}[2] => Command = Receive
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    UART => If ${ResultComponents}[1] (Function) is not equal to "UART" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Receive => If ${ResultComponents}[2] (Command) is not equal to "Receive" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    04 => If ${ResultComponents}[4] (Received data length) is not equal to "04" then the test is not passed
    Should Be Equal    ${ResultComponents}[5]    ABCDabcd => If ${ResultComponents}[5] (Received data) is not equal to "ABCDabcd" then the test is not passed

UART_Commands_ReceiveW

This function waits to receive the specified number of bytes of data through the ISR (Interrupt Service Routine) receive buffer of the UART
This command may invoke FH_UART_ReceiveW_UART01 to FH_UART_ReceiveW_UART08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_UART (0x06)
Command	FH_UART_Commands_ReceiveW (0x03)
MessageDataLength	6 bytes (0x06)
MessageData1	UART Input Number (0x01 for UART01 to 0x08 for UART08)
MessageData2	The expected number of bytes of data to be received (Example: 5 bytes => 0x05))
MessageData3	The timeout of receiving the expected number of bytes in mili seconds, Byte 4
MessageData4	The timeout of receiving the expected number of bytes in mili seconds, Byte 3
MessageData5	The timeout of receiving the expected number of bytes in mili seconds, Byte 2
MessageData6	The timeout of receiving the expected number of bytes in mili seconds, Byte 1
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"UART"
Command (7 bytes)	"ReceiveW"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of the UART receive buffer index value (Length of the received data)
MessageData3 (2 bytes)	Ascii equivalent of the hex value of the UART receive buffer value byte 1
MessageData... (2 bytes)	Ascii equivalent of the hex value of the UART receive buffer value byte ...
MessageDataN (2 bytes)	Ascii equivalent of the hex value of the UART receive buffer value byte N

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${UART01}    05    00    00    0B    B8
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_UART}    Command=${UART_Commands_ReceiveW}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    DataLength =    ${ResultComponents}[4]
    Log Many    Data =    ${ResultComponents}[5]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    UART
    Should Be Equal    ${ResultComponents}[2]    ReceiveW
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}
    Should Be Equal    ${ResultComponents}[4]    04
    Should Be Equal    ${ResultComponents}[5]    ABCDabcd

    Comments:

    UART01 => It indicates the UART 01
    05 => The expected number of bytes of data to be received through the <b>ISR</b> (Interrupt Service Routine) receive buffer (FH_UART01_ReceiveBuf) of the <b>UART 01</b>
    00    00    0B    B8 => Example data (0x00000BB8 milliseconds) as timeout of receiving the expected number of bytes
                            FH_GlobalTimeCounter which is a global variable is utilized to calculate the timeout
                            FH_GlobalTimeCounter shall be incremented every <b>1 millisecond</b> in an interested timer <b>ISR</b> (Interrupt Service Routine) by <b>FH</b> user
                            For this to happen, <b>FH_GlobalTimerCount.h</b> shall be included in the interested timer <b>ISR</b> (Interrupt Service Routine) file
                            If the expected number of bytes are received, the function does not wait anymore for the remaining time of the timeout
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_UART => It is the function in the message frame
    UART_Commands_ReceiveW => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|UART|ReceiveW|00|04|ABCDabcd
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = UART
    Log Many    Command =    ${ResultComponents}[2] => Command = ReceiveW
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    UART => If ${ResultComponents}[1] (Function) is not equal to "UART" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    ReceiveW => If ${ResultComponents}[2] (Command) is not equal to "ReceiveW" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    04 => If ${ResultComponents}[4] (Received data length) is not equal to "04" then the test is not passed
    Should Be Equal    ${ResultComponents}[5]    ABCDabcd => If ${ResultComponents}[5] (Received data) is not equal to "ABCDabcd" then the test is not passed

UART_Commands_ResetRB

This function resets the ISR (Interrupt Service Routine) receive buffer index of the UART
This command may invoke FH_UART_ResetRB_UART01 to FH_UART_ResetRB_UART08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_UART (0x06)
Command	FH_UART_Commands_ResetRB (0x04)
MessageDataLength	1 bytes (0x01)
MessageData	UART Input Number (0x01 for UART01 to 0x08 for UART08)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"UART"
Command (7 bytes)	"ResetRB"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${UART01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_UART}    Command=${UART_Commands_ResetRB}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    UART
    Should Be Equal    ${ResultComponents}[2]    ResetRB
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    UART01 => It indicates the UART 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_UART => It is the function in the message frame
    UART_Commands_ResetRB => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|UART|ResetRB|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = UART
    Log Many    Command =    ${ResultComponents}[2] => Command = ResetRB
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    UART => If ${ResultComponents}[1] (Function) is not equal to "UART" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    ResetRB => If ${ResultComponents}[2] (Command) is not equal to "ResetRB" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

UART_Commands_SSD8

This function sets the shared data buffer (8 bit buffer) of the UART
This command may invoke FH_UART_SSD8_UART01 to FH_UART_SSD8_UART08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_UART (0x06)
Command	FH_UART_Commands_SSD8 (0x05)
MessageDataLength	N bytes (Example: N = 5 => 0x05)
MessageData1	UART Number (0x01 for UART01 to 0x08 for UART08)
MessageData2	Length of the data to be set
MessageData3	Data1 to be set
MessageData...	Data... to be set
MessageDataN	DataN to be set
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"UART"
Command (4 bytes)	"SSD8"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${UART01}    04    AA    BB    CC    DD
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_UART}    Command=${UART_Commands_SSD8}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    UART
    Should Be Equal    ${ResultComponents}[2]    SSD8
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok}

    Comments:

    UART01 => It indicates the UART 01
    04 => Example interested length of the 8 bit data to be set
    AA    BB    CC    DD => Example data (0xAA, 0xBB, 0xCC, 0xDD) to be set in <b>FH_UART01_SharedDataBuf_8Bits</b>
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_UART => It is the function in the message frame
    UART_Commands_SSD8 => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|UART|SSD8|01|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = UART
    Log Many    Command =    ${ResultComponents}[2] => Command = SSD8
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    UART => If ${ResultComponents}[1] (Function) is not equal to "UART" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    SSD8 => If ${ResultComponents}[2] (Command) is not equal to "SSD8" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_Ok} (01)" then the test is not passed

UART_Commands_SSD16

This function sets the shared data buffer (16 bit buffer) of the UART
This command may invoke FH_UART_SSD16_UART01 to FH_UART_SSD16_UART08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_UART (0x06)
Command	FH_UART_Commands_SSD16 (0x06)
MessageDataLength	N bytes (Example: N = 5 => 0x05)
MessageData1	UART Number (0x01 for UART01 to 0x08 for UART08)
MessageData2	Length of the data to be set
MessageData3	Data1 byte1 (high byte) to be set
MessageData4	Data1 byte2 (low byte)to be set
MessageData5	Data2 byte1 (high byte) to be set
MessageData6	Data2 byte2 (low byte)to be set
MessageData...	Data... byte1 (high byte) to be set
MessageData...	Data... byte2 (low byte) to be set
MessageDataN-1	DataN byte1 (high byte) to be set
MessageDataN	DataN byte2 (low byte) to be set
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"UART"
Command (4 bytes)	"SSD16"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${UART01}    02    AA    BB    CC    DD
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_UART}    Command=${UART_Commands_SSD16}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    UART
    Should Be Equal    ${ResultComponents}[2]    SSD16
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok}

    Comments:

    UART01 => It indicates the UART 01
    02 => Example interested length of the 16 bit data to be set
    AA    BB    CC    DD => Example data (0xAABB and 0xCCDD) to be set in <b>FH_UART01_SharedDataBuf_16Bits</b>
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_UART => It is the function in the message frame
    UART_Commands_SSD16 => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|UART|SSD16|01|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = UART
    Log Many    Command =    ${ResultComponents}[2] => Command = SSD16
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    UART => If ${ResultComponents}[1] (Function) is not equal to "UART" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    SSD16 => If ${ResultComponents}[2] (Command) is not equal to "SSD16" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_Ok} (01)" then the test is not passed

UART_Commands_SSD32

This function sets the shared data buffer (32 bit buffer) of the UART
This command may invoke FH_UART_SSD32_UART01 to FH_UART_SSD32_UART08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_UART (0x06)
Command	FH_UART_Commands_SSD32 (0x07)
MessageDataLength	N bytes (Example: N = 5 => 0x05)
MessageData1	UART Number (0x01 for UART01 to 0x08 for UART08)
MessageData2	Length of the data to be set
MessageData3	Data1 byte1 (4th byte) to be set
MessageData4	Data1 byte2 (3rd byte)to be set
MessageData5	Data1 byte3 (2nd byte) to be set
MessageData6	Data1 byte4 (1st byte)to be set
MessageData3	Data2 byte1 (4th byte) to be set
MessageData4	Data2 byte2 (3rd byte)to be set
MessageData5	Data2 byte3 (2nd byte) to be set
MessageData6	Data2 byte4 (1st byte)to be set
MessageData...	Data... byte1 (4th byte) to be set
MessageData...	Data... byte2 (3rd byte) to be set
MessageData...	Data... byte3 (2nd byte) to be set
MessageData...	Data... byte4 (1st byte) to be set
MessageDataN-3	DataN byte1 (4th byte) to be set
MessageDataN-2	DataN byte2 (3rd byte) to be set
MessageDataN-1	DataN byte3 (2nd byte) to be set
MessageDataN	DataN byte4 (1st byte) to be set
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"UART"
Command (4 bytes)	"SSD32"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

        ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${UART01}    02    AA    BB    CC    DD    01    02    03    04
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_UART}    Command=${UART_Commands_SSD32}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    UART
    Should Be Equal    ${ResultComponents}[2]    SSD32
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok}

    Comments:

    UART01 => It indicates the UART 01
    02 => Example interested length of the 32 bit data to be set
    AA    BB    CC    DD    01    02    03    04 => Example data (0xAABBCCDD and 0x01020304) to be set in <b>FH_UART01_SharedDataBuf_32Bits</b>
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_UART => It is the function in the message frame
    UART_Commands_SSD32 => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|UART|SSD32|01|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = UART
    Log Many    Command =    ${ResultComponents}[2] => Command = SSD32
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    UART => If ${ResultComponents}[1] (Function) is not equal to "UART" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    SSD32 => If ${ResultComponents}[2] (Command) is not equal to "SSD32" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_Ok} (01)" then the test is not passed

UART_Commands_GSD8

This function gets the shared data buffer (8 bit buffer) of the UART
This command may invoke FH_UART_GSD8_UART01 to FH_UART_GSD8_UART08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_UART (0x06)
Command	FH_UART_Commands_GSD8 (0x08)
MessageDataLength	1 byte (0x01)
MessageData	UART Input Number (0x01 for UART01 to 0x08 for UART08)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"UART"
Command (7 bytes)	"GSD8"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer index value (Length of the shared data buffer)
MessageData3 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data1
MessageData... (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data ...
MessageDataN (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value DataN

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${UART01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_UART}    Command=${UART_Commands_GSD8}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    DataLength =    ${ResultComponents}[4]
    Log Many    Data =    ${ResultComponents}[5]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    UART
    Should Be Equal    ${ResultComponents}[2]    GSD8
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok}
    Should Be Equal    ${ResultComponents}[4]    10
    Should Be Equal    ${ResultComponents}[5]    aabbccdd000000000000000000000000

    Comments:

    UART01 => It indicates the UART 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_UART => It is the function in the message frame
    UART_Commands_GSD8 => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|UART|GSD8|01|10|aabbccdd000000000000000000000000
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = UART
    Log Many    Command =    ${ResultComponents}[2] => Command = GSD8
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    UART => If ${ResultComponents}[1] (Function) is not equal to "UART" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    GSD8 => If ${ResultComponents}[2] (Command) is not equal to "GSD8" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_Ok} (01)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    10 => If ${ResultComponents}[4] (Shared data length) is not equal to "10" then the test is not passed
    Should Be Equal    ${ResultComponents}[5]    aabbccdd000000000000000000000000 => If ${ResultComponents}[5] (Shared data) is not equal to "aabbccdd000000000000000000000000" then the test is not passed

UART_Commands_GSD16

This function gets the shared data buffer (16 bit buffer) of the UART
This command may invoke FH_UART_GSD16_UART01 to FH_UART_GSD16_UART08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_UART (0x06)
Command	FH_UART_Commands_GSD16 (0x09)
MessageDataLength	1 byte (0x01)
MessageData	UART Input Number (0x01 for UART01 to 0x08 for UART08)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"UART"
Command (7 bytes)	"GSD16"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer index value (Length of the shared data buffer)
MessageData3 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data1 byte 1 (high byte)
MessageData4 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data2 byte 2 (low byte)
MessageData... (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data... byte 1 (high byte)
MessageData... (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data... byte 2 (low byte)
MessageDataN-1 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value DataN-1 byte 1 (high byte)
MessageDataN (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value DataN byte 2 (low byte)

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${UART01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_UART}    Command=${UART_Commands_GSD16}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    DataLength =    ${ResultComponents}[4]
    Log Many    Data =    ${ResultComponents}[5]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    UART
    Should Be Equal    ${ResultComponents}[2]    GSD16
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok}
    Should Be Equal    ${ResultComponents}[4]    10
    Should Be Equal    ${ResultComponents}[5]    aabbccdd000000000000000000000000

    Comments:

    UART01 => It indicates the UART 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_UART => It is the function in the message frame
    UART_Commands_GSD16 => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|UART|GSD16|01|10|aabbccdd000000000000000000000000
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = UART
    Log Many    Command =    ${ResultComponents}[2] => Command = GSD16
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    UART => If ${ResultComponents}[1] (Function) is not equal to "UART" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    GSD16 => If ${ResultComponents}[2] (Command) is not equal to "GSD16" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_Ok} (01)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    10 => If ${ResultComponents}[4] (Shared data length) is not equal to "10" then the test is not passed
    Should Be Equal    ${ResultComponents}[5]    aabbccdd000000000000000000000000 => If ${ResultComponents}[5] (Shared data) is not equal to "aabbccdd000000000000000000000000" then the test is not passed

UART_Commands_GSD32

This function gets the shared data buffer (32 bit buffer) of the UART
This command may invoke FH_UART_GSD32_UART01 to FH_UART_GSD32_UART08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_UART (0x06)
Command	FH_UART_Commands_GSD32 (0x0A)
MessageDataLength	1 byte (0x01)
MessageData	UART Input Number (0x01 for UART01 to 0x08 for UART08)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"UART"
Command (7 bytes)	"GSD32"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer index value (Length of the shared data buffer)
MessageData3 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data1 byte 1 (4th byte)
MessageData4 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data1 byte 2 (3rd byte)
MessageData5 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data1 byte 3 (2nd byte)
MessageData6 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data1 byte 4 (1st byte)
MessageData... (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data... byte 1 (4th byte)
MessageData... (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data... byte 2 (3rd byte)
MessageData... (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data... byte 3 (2nd byte)
MessageData... (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value Data... byte 4 (1st byte)
MessageDataN-3 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value DataN byte 1 (4th byte)
MessageDataN-2 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value DataN byte 2 (3rd byte)
MessageDataN-1 (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value DataN byte 3 (2nd byte)
MessageDataN (2 bytes)	Ascii equivalent of the hex value of the UART shared data buffer value DataN byte 4 (1st byte)

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${UART01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_UART}    Command=${UART_Commands_GSD32}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    DataLength =    ${ResultComponents}[4]
    Log Many    Data =    ${ResultComponents}[5]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    UART
    Should Be Equal    ${ResultComponents}[2]    GSD32
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok}
    Should Be Equal    ${ResultComponents}[4]    10
    Should Be Equal    ${ResultComponents}[5]    aabbccdd010203040000000000000000

    Comments:

    UART01 => It indicates the UART 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_UART => It is the function in the message frame
    UART_Commands_GSD32 => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|UART|GSD32|01|10|aabbccdd010203040000000000000000
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = UART
    Log Many    Command =    ${ResultComponents}[2] => Command = GSD32
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    UART => If ${ResultComponents}[1] (Function) is not equal to "UART" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    GSD32 => If ${ResultComponents}[2] (Command) is not equal to "GSD32" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_Ok} (01)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    10 => If ${ResultComponents}[4] (Shared data length) is not equal to "10" then the test is not passed
    Should Be Equal    ${ResultComponents}[5]    aabbccdd010203040000000000000000 => If ${ResultComponents}[5] (Shared data) is not equal to "aabbccdd010203040000000000000000" then the test is not passed

CAN Messages

Message	Description
CAN_Commands_Init	Initializes a CAN
CAN_Commands_Send	Sends data through the CAN
CAN_Commands_Receive	Retrieves the ISR (Interrupt Service Routine) receive buffer of the CAN
CAN_Commands_ReceiveW	Waits to receive the specified number of bytes of data through the ISR (Interrupt Service Routine) receive buffer of the CAN
CAN_Commands_ResetRB	Resets the ISR (Interrupt Service Routine) receive buffer index of the CAN
CAN_Commands_SSD8	Sets the shared data buffer (8 bit buffer) of the CAN
CAN_Commands_SSD16	Sets the shared data buffer (16 bit buffer) of the CAN
CAN_Commands_SSD32	Sets the shared data buffer (32 bit buffer) of the CAN
CAN_Commands_GSSD8	Gets the shared data buffer (8 bit buffer) of the CAN
CAN_Commands_GSD16	Gets the shared data buffer (16 bit buffer) of the CAN
CAN_Commands_GSD32	Gets the shared data buffer (32 bit buffer) of the CAN

CAN_Commands_Init

This command initializes a CAN
This command may invoke FH_CAN_Init_CAN01 to FH_CAN_Init_CAN08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_CAN (0x06)
Command	CAN_Commands_Init (0x00)
MessageDataLength	1 byte (0x01)
MessageData	CAN Number (0x01 for CAN01 to 0x08 for CAN08)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (2 bytes)	"CAN"
Command (4 bytes)	"Init"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${CAN01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_CAN}    Command=${CAN_Commands_Init}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    CAN
    Should Be Equal    ${ResultComponents}[2]    Init
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    CAN01 => It indicates the CAN 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_CAN => It is the function in the message frame
    CAN_Commands_Init => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|CAN|Init|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = CAN
    Log Many    Command =    ${ResultComponents}[2] => Command = Init
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    CAN => If ${ResultComponents}[1] (Function) is not equal to "CAN" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Init => If ${ResultComponents}[2] (Command) is not equal to "Init" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

CAN_Commands_Send

This command sends data through the CAN
This command may invoke FH_CAN_Send_CAN01 to FH_CAN_Send_CAN08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_CAN (0x06)
Command	CAN_Commands_Send (0x01)
MessageDataLength	N bytes (Example: N = 5 => 0x05)
MessageData1	CAN Number (0x01 for CAN01 to 0x08 for CAN08)
MessageData2	Length of the data to be sent
MessageData3	Data byte1 to be sent
MessageData...	Data byte... to be sent
MessageDataN	Data byteN to be sent
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"CAN"
Command (4 bytes)	"Send"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${CAN01}    02    B1    FF
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_CAN}    Command=${CAN_Commands_Send}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    CAN
    Should Be Equal    ${ResultComponents}[2]    Send
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    CAN01 => It indicates the CAN 01
    02 => Example length of the data to be sent
    B1     FF => Example data (0xB1, 0xFF) to be sent (or apart from the data to be sent, it may include some other data like ID, Filter, ... to be processed too, if need be) through the <b>CAN 01</b>\n
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_CAN => It is the function in the message frame
    CAN_Commands_Send => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|CAN|Send|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = CAN
    Log Many    Command =    ${ResultComponents}[2] => Command = Send
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    CAN => If ${ResultComponents}[1] (Function) is not equal to "CAN" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Send => If ${ResultComponents}[2] (Command) is not equal to "Send" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

CAN_Commands_Receive

This function retrieves the ISR (Interrupt Service Routine) receive buffer of the CAN
This command may invoke FH_CAN_Receive_CAN01 to FH_CAN_Receive_CAN08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_CAN (0x06)
Command	CAN_Commands_Receive (0x02)
MessageDataLength	1 byte (0x01)
MessageData	CAN Input Number (0x01 for CAN01 to 0x08 for CAN08)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"CAN"
Command (7 bytes)	"Receive"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of the CAN receive buffer index value (Length of the received data)
MessageData3 (2 bytes)	Ascii equivalent of the hex value of the CAN receive buffer value byte 1
MessageData... (2 bytes)	Ascii equivalent of the hex value of the CAN receive buffer value byte ...
MessageDataN (2 bytes)	Ascii equivalent of the hex value of the CAN receive buffer value byte N

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${CAN01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_CAN}    Command=${CAN_Commands_Receive}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    DataLength =    ${ResultComponents}[4]
    Log Many    Data =    ${ResultComponents}[5]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    CAN
    Should Be Equal    ${ResultComponents}[2]    Receive
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}
    Should Be Equal    ${ResultComponents}[4]    04
    Should Be Equal    ${ResultComponents}[5]    ABCDabcd

    Comments:

    CAN01 => It indicates the CAN 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_CAN => It is the function in the message frame
    CAN_Commands_Receive => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|CAN|Receive|00|04|ABCDabcd
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = CAN
    Log Many    Command =    ${ResultComponents}[2] => Command = Receive
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    CAN => If ${ResultComponents}[1] (Function) is not equal to "CAN" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Receive => If ${ResultComponents}[2] (Command) is not equal to "Receive" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    04 => If ${ResultComponents}[4] (Received data length) is not equal to "04" then the test is not passed
    Should Be Equal    ${ResultComponents}[5]    ABCDabcd => If ${ResultComponents}[5] (Received data) is not equal to "ABCDabcd" then the test is not passed

CAN_Commands_ReceiveW

This function waits to receive the specified number of bytes of data through the ISR (Interrupt Service Routine) receive buffer of the CAN
This command may invoke FH_CAN_ReceiveW_CAN01 to FH_CAN_ReceiveW_CAN08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_CAN (0x06)
Command	FH_CAN_Commands_ReceiveW (0x03)
MessageDataLength	6 bytes (0x06)
MessageData1	CAN Input Number (0x01 for CAN01 to 0x08 for CAN08)
MessageData2	The expected number of bytes of data to be received (Example: 5 bytes => 0x05))
MessageData3	The timeout of receiving the expected number of bytes in mili seconds, Byte 4
MessageData4	The timeout of receiving the expected number of bytes in mili seconds, Byte 3
MessageData5	The timeout of receiving the expected number of bytes in mili seconds, Byte 2
MessageData6	The timeout of receiving the expected number of bytes in mili seconds, Byte 1
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"CAN"
Command (7 bytes)	"ReceiveW"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of the CAN receive buffer index value (Length of the received data)
MessageData3 (2 bytes)	Ascii equivalent of the hex value of the CAN receive buffer value byte 1
MessageData... (2 bytes)	Ascii equivalent of the hex value of the CAN receive buffer value byte ...
MessageDataN (2 bytes)	Ascii equivalent of the hex value of the CAN receive buffer value byte N

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${CAN01}    05    00    00    0B    B8
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_CAN}    Command=${CAN_Commands_ReceiveW}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    DataLength =    ${ResultComponents}[4]
    Log Many    Data =    ${ResultComponents}[5]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    CAN
    Should Be Equal    ${ResultComponents}[2]    ReceiveW
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}
    Should Be Equal    ${ResultComponents}[4]    05
    Should Be Equal    ${ResultComponents}[5]    ABCDabcd
    Comments:

    CAN01 => It indicates the CAN 01
    05 => The expected number of bytes of data to be received through the <b>ISR</b> (Interrupt Service Routine) receive buffer (FH_CAN01_ReceiveBuf) of the <b>CAN 01</b>
    00    00    0B    B8 => Example data (0x00000BB8 milliseconds) as timeout of receiving the expected number of bytes
                            FH_GlobalTimeCounter which is a global variable is utilized to calculate the timeout
                            FH_GlobalTimeCounter shall be incremented every <b>1 millisecond</b> in an interested timer <b>ISR</b> (Interrupt Service Routine) by <b>FH</b> user
                            For this to happen, <b>FH_GlobalTimerCount.h</b> shall be included in the interested timer <b>ISR</b> (Interrupt Service Routine) file
                            If the expected number of bytes are received, the function does not wait anymore for the remaining time of the timeout
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_CAN => It is the function in the message frame
    CAN_Commands_ReceiveW => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|CAN|ReceiveW|00|04|ABCDabcd
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = CAN
    Log Many    Command =    ${ResultComponents}[2] => Command = ReceiveW
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    CAN => If ${ResultComponents}[1] (Function) is not equal to "CAN" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    ReceiveW => If ${ResultComponents}[2] (Command) is not equal to "ReceiveW" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    04 => If ${ResultComponents}[4] (Received data length) is not equal to "04" then the test is not passed
    Should Be Equal    ${ResultComponents}[5]    ABCDabcd => If ${ResultComponents}[5] (Received data) is not equal to "ABCDabcd" then the test is not passed

CAN_Commands_ResetRB

This function resets the ISR (Interrupt Service Routine) receive buffer index of the CAN
This command may invoke FH_CAN_ResetRB_CAN01 to FH_CAN_ResetRB_CAN08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_CAN (0x06)
Command	FH_CAN_Commands_ResetRB (0x04)
MessageDataLength	1 bytes (0x01)
MessageData	CAN Input Number (0x01 for CAN01 to 0x08 for CAN08)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"CAN"
Command (7 bytes)	"ResetRB"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${CAN01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_CAN}    Command=${CAN_Commands_ResetRB}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    CAN
    Should Be Equal    ${ResultComponents}[2]    ResetRB
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    CAN01 => It indicates the CAN 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_CAN => It is the function in the message frame
    CAN_Commands_ResetRB => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|CAN|ResetRB|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = CAN
    Log Many    Command =    ${ResultComponents}[2] => Command = ResetRB
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    CAN => If ${ResultComponents}[1] (Function) is not equal to "CAN" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    ResetRB => If ${ResultComponents}[2] (Command) is not equal to "ResetRB" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

CAN_Commands_SSD8

This function sets the shared data buffer (8 bit buffer) of the CAN
This command may invoke FH_CAN_SSD8_CAN01 to FH_CAN_SSD8_CAN08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_CAN (0x06)
Command	FH_CAN_Commands_SSD8 (0x05)
MessageDataLength	N bytes (Example: N = 5 => 0x05)
MessageData1	CAN Number (0x01 for CAN01 to 0x08 for CAN08)
MessageData2	Length of the data to be set
MessageData3	Data1 to be set
MessageData...	Data... to be set
MessageDataN	DataN to be set
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"CAN"
Command (4 bytes)	"SSD8"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${CAN01}    04    AA    BB    CC    DD
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_CAN}    Command=${CAN_Commands_SSD8}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    CAN
    Should Be Equal    ${ResultComponents}[2]    SSD8
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok}

    Comments:

    CAN01 => It indicates the CAN 01
    04 => Example interested length of the 8 bit data to be set
    AA    BB    CC    DD => Example data (0xAA, 0xBB, 0xCC, 0xDD) to be set in <b>FH_CAN01_SharedDataBuf_8Bits</b>
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_CAN => It is the function in the message frame
    CAN_Commands_SSD8 => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|CAN|SSD8|01|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = CAN
    Log Many    Command =    ${ResultComponents}[2] => Command = SSD8
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    CAN => If ${ResultComponents}[1] (Function) is not equal to "CAN" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    SSD8 => If ${ResultComponents}[2] (Command) is not equal to "SSD8" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_Ok} (01)" then the test is not passed

CAN_Commands_SSD16

This function sets the shared data buffer (16 bit buffer) of the CAN
This command may invoke FH_CAN_SSD16_CAN01 to FH_CAN_SSD16_CAN08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_CAN (0x06)
Command	FH_CAN_Commands_SSD16 (0x06)
MessageDataLength	N bytes (Example: N = 5 => 0x05)
MessageData1	CAN Number (0x01 for CAN01 to 0x08 for CAN08)
MessageData2	Length of the data to be set
MessageData3	Data1 byte1 (high byte) to be set
MessageData4	Data1 byte2 (low byte)to be set
MessageData5	Data2 byte1 (high byte) to be set
MessageData6	Data2 byte2 (low byte)to be set
MessageData...	Data... byte1 (high byte) to be set
MessageData...	Data... byte2 (low byte) to be set
MessageDataN-1	DataN byte1 (high byte) to be set
MessageDataN	DataN byte2 (low byte) to be set
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"CAN"
Command (4 bytes)	"SSD16"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${CAN01}    02    AA    BB    CC    DD
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_CAN}    Command=${CAN_Commands_SSD16}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    CAN
    Should Be Equal    ${ResultComponents}[2]    SSD16
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok}

    Comments:

    CAN01 => It indicates the CAN 01
    02 => Example interested length of the 16 bit data to be set
    AA    BB    CC    DD => Example data (0xAABB and 0xCCDD) to be set in <b>FH_CAN01_SharedDataBuf_16Bits</b>
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_CAN => It is the function in the message frame
    CAN_Commands_SSD16 => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|CAN|SSD16|01|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = CAN
    Log Many    Command =    ${ResultComponents}[2] => Command = SSD16
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    CAN => If ${ResultComponents}[1] (Function) is not equal to "CAN" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    SSD16 => If ${ResultComponents}[2] (Command) is not equal to "SSD16" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_Ok} (01)" then the test is not passed

CAN_Commands_SSD32

This function sets the shared data buffer (32 bit buffer) of the CAN
This command may invoke FH_CAN_SSD32_CAN01 to FH_CAN_SSD32_CAN08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_CAN (0x06)
Command	FH_CAN_Commands_SSD32 (0x07)
MessageDataLength	N bytes (Example: N = 5 => 0x05)
MessageData1	CAN Number (0x01 for CAN01 to 0x08 for CAN08)
MessageData2	Length of the data to be set
MessageData3	Data1 byte1 (4th byte) to be set
MessageData4	Data1 byte2 (3rd byte)to be set
MessageData5	Data1 byte3 (2nd byte) to be set
MessageData6	Data1 byte4 (1st byte)to be set
MessageData3	Data2 byte1 (4th byte) to be set
MessageData4	Data2 byte2 (3rd byte)to be set
MessageData5	Data2 byte3 (2nd byte) to be set
MessageData6	Data2 byte4 (1st byte)to be set
MessageData...	Data... byte1 (4th byte) to be set
MessageData...	Data... byte2 (3rd byte) to be set
MessageData...	Data... byte3 (2nd byte) to be set
MessageData...	Data... byte4 (1st byte) to be set
MessageDataN-3	DataN byte1 (4th byte) to be set
MessageDataN-2	DataN byte2 (3rd byte) to be set
MessageDataN-1	DataN byte3 (2nd byte) to be set
MessageDataN	DataN byte4 (1st byte) to be set
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"CAN"
Command (4 bytes)	"SSD32"
MessageData (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

        ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${CAN01}    02    AA    BB    CC    DD    01    02    03    04
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_CAN}    Command=${CAN_Commands_SSD32}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    CAN
    Should Be Equal    ${ResultComponents}[2]    SSD32
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok}

    Comments:

    CAN01 => It indicates the CAN 01
    02 => Example interested length of the 32 bit data to be set
    AA    BB    CC    DD    01    02    03    04 => Example data (0xAABBCCDD and 0x01020304) to be set in <b>FH_CAN01_SharedDataBuf_32Bits</b>
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_CAN => It is the function in the message frame
    CAN_Commands_SSD32 => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|CAN|SSD32|01|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = CAN
    Log Many    Command =    ${ResultComponents}[2] => Command = SSD32
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    CAN => If ${ResultComponents}[1] (Function) is not equal to "CAN" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    SSD32 => If ${ResultComponents}[2] (Command) is not equal to "SSD32" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_Ok} (01)" then the test is not passed

CAN_Commands_GSD8

This function gets the shared data buffer (8 bit buffer) of the CAN
This command may invoke FH_CAN_GSD8_CAN01 to FH_CAN_GSD8_CAN08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_CAN (0x06)
Command	FH_CAN_Commands_GSD8 (0x08)
MessageDataLength	1 byte (0x01)
MessageData	CAN Input Number (0x01 for CAN01 to 0x08 for CAN08)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"CAN"
Command (7 bytes)	"GSD8"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer index value (Length of the shared data buffer)
MessageData3 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data1
MessageData... (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data ...
MessageDataN (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value DataN

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${CAN01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_CAN}    Command=${CAN_Commands_GSD8}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    DataLength =    ${ResultComponents}[4]
    Log Many    Data =    ${ResultComponents}[5]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    CAN
    Should Be Equal    ${ResultComponents}[2]    GSD8
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok}
    Should Be Equal    ${ResultComponents}[4]    10
    Should Be Equal    ${ResultComponents}[5]    aabbccdd000000000000000000000000

    Comments:

    CAN01 => It indicates the CAN 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_CAN => It is the function in the message frame
    CAN_Commands_GSD8 => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|CAN|GSD8|01|10|aabbccdd000000000000000000000000
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = CAN
    Log Many    Command =    ${ResultComponents}[2] => Command = GSD8
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    CAN => If ${ResultComponents}[1] (Function) is not equal to "CAN" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    GSD8 => If ${ResultComponents}[2] (Command) is not equal to "GSD8" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_Ok} (01)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    10 => If ${ResultComponents}[4] (Shared data length) is not equal to "10" then the test is not passed
    Should Be Equal    ${ResultComponents}[5]    aabbccdd000000000000000000000000 => If ${ResultComponents}[5] (Shared data) is not equal to "aabbccdd000000000000000000000000" then the test is not passed

CAN_Commands_GSD16

This function gets the shared data buffer (16 bit buffer) of the CAN
This command may invoke FH_CAN_GSD16_CAN01 to FH_CAN_GSD16_CAN08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_CAN (0x06)
Command	FH_CAN_Commands_GSD16 (0x09)
MessageDataLength	1 byte (0x01)
MessageData	CAN Input Number (0x01 for CAN01 to 0x08 for CAN08)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"CAN"
Command (7 bytes)	"GSD16"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer index value (Length of the shared data buffer)
MessageData3 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data1 byte 1 (high byte)
MessageData4 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data2 byte 2 (low byte)
MessageData... (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data... byte 1 (high byte)
MessageData... (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data... byte 2 (low byte)
MessageDataN-1 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value DataN-1 byte 1 (high byte)
MessageDataN (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value DataN byte 2 (low byte)

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${CAN01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_CAN}    Command=${CAN_Commands_GSD16}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    DataLength =    ${ResultComponents}[4]
    Log Many    Data =    ${ResultComponents}[5]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    CAN
    Should Be Equal    ${ResultComponents}[2]    GSD16
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok}
    Should Be Equal    ${ResultComponents}[4]    10
    Should Be Equal    ${ResultComponents}[5]    aabbccdd000000000000000000000000

    Comments:

    CAN01 => It indicates the CAN 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_CAN => It is the function in the message frame
    CAN_Commands_GSD16 => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|CAN|GSD16|01|10|aabbccdd000000000000000000000000
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = CAN
    Log Many    Command =    ${ResultComponents}[2] => Command = GSD16
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    CAN => If ${ResultComponents}[1] (Function) is not equal to "CAN" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    GSD16 => If ${ResultComponents}[2] (Command) is not equal to "GSD16" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_Ok} (01)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    10 => If ${ResultComponents}[4] (Shared data length) is not equal to "10" then the test is not passed
    Should Be Equal    ${ResultComponents}[5]    aabbccdd000000000000000000000000 => If ${ResultComponents}[5] (Shared data) is not equal to "aabbccdd000000000000000000000000" then the test is not passed

CAN_Commands_GSD32

This function gets the shared data buffer (32 bit buffer) of the CAN
This command may invoke FH_CAN_GSD32_CAN01 to FH_CAN_GSD32_CAN08

Send Message Body	Description
DeviceAddress	It shall be equal to the address of the device (FH_RFCommunication_DeviceAddress)
Function	Function_CAN (0x06)
Command	FH_CAN_Commands_GSD32 (0x0A)
MessageDataLength	1 byte (0x01)
MessageData	CAN Input Number (0x01 for CAN01 to 0x08 for CAN08)
Checksum	Sum of all the bytes (For user-friendly design purposes, not implemented => always 0xAA)

Result Message Body	Description
DeviceAddress (2 bytes)	Ascii equivalent of the hex address of the device (FH_RFCommunication_DeviceAddress)
Function (4 bytes)	"CAN"
Command (7 bytes)	"GSD32"
MessageData1 (2 bytes)	Ascii equivalent of the hex value of the Error Code (XX) in FH_ErrorInfo.h
MessageData2 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer index value (Length of the shared data buffer)
MessageData3 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data1 byte 1 (4th byte)
MessageData4 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data1 byte 2 (3rd byte)
MessageData5 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data1 byte 3 (2nd byte)
MessageData6 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data1 byte 4 (1st byte)
MessageData... (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data... byte 1 (4th byte)
MessageData... (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data... byte 2 (3rd byte)
MessageData... (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data... byte 3 (2nd byte)
MessageData... (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value Data... byte 4 (1st byte)
MessageDataN-3 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value DataN byte 1 (4th byte)
MessageDataN-2 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value DataN byte 2 (3rd byte)
MessageDataN-1 (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value DataN byte 3 (2nd byte)
MessageDataN (2 bytes)	Ascii equivalent of the hex value of the CAN shared data buffer value DataN byte 4 (1st byte)

Remarks: Result Message Body elements are separated by "|" and apart from that "\n" is sent at the end of the Result Message Body too

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${CAN01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_CAN}    Command=${CAN_Commands_GSD32}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Log Many    DataLength =    ${ResultComponents}[4]
    Log Many    Data =    ${ResultComponents}[5]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    CAN
    Should Be Equal    ${ResultComponents}[2]    GSD32
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok}
    Should Be Equal    ${ResultComponents}[4]    10
    Should Be Equal    ${ResultComponents}[5]    aabbccdd010203040000000000000000

    Comments:

    CAN01 => It indicates the CAN 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_CAN => It is the function in the message frame
    CAN_Commands_GSD32 => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|CAN|GSD32|01|10|aabbccdd010203040000000000000000
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = CAN
    Log Many    Command =    ${ResultComponents}[2] => Command = GSD32
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    CAN => If ${ResultComponents}[1] (Function) is not equal to "CAN" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    GSD32 => If ${ResultComponents}[2] (Command) is not equal to "GSD32" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_Ok} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_Ok} (01)" then the test is not passed
    Should Be Equal    ${ResultComponents}[4]    10 => If ${ResultComponents}[4] (Shared data length) is not equal to "10" then the test is not passed
    Should Be Equal    ${ResultComponents}[5]    aabbccdd010203040000000000000000 => If ${ResultComponents}[5] (Shared data) is not equal to "aabbccdd010203040000000000000000" then the test is not passed

Quick Setup

FH RobotFramework source code (HIL simulator computer side)

Install RobotFramework

==========================================================================================================================
                      ##### Example of installing RobotFramework with pip for Windows #####
==========================================================================================================================
Step 1 - Install Python
Step 2 - pip should be installed through the step 1
Step 3 - pip install robotframework
Step 4 - pip install robotframework-ride
Step 5 - pip install robotframework-seriallibrary

For more information refer to Robot Framework User Guide

FH Embedded Software source code (HIL simulator hardware side)

1 - Simply copy and place FH_Embedded directory in your own source code of your interested microcontroller:

FH_Embedded directory includes FH_Functions, FH_Root and FH_Setup
FH Embedded Software source code is independent of the microcontrollers and should be simply compiled without the need for any modification

2 - Set up a device address in FH Embedded Software source code:

Go to FH_Setup => FH_DeviceAddress => FH_DeviceAddress.h
Set the mentioned FH_RFCommunication_DeviceAddress as device (card) address
Or leave it intact as 0x01 if there is just one device (card) (there is no RS485 network)

3 - Set the maximum number of peripherals for your interested HIL Simulator:

Go to FH_Setup => FH_DevicePeripherals => FH_DevicePeripherals.h

4 - Set up a Communication Dedicated UART in FH Embedded Software source code:

1 - Baud rate => 115200;
2 - Data size => 8 bits;
3 - Stop bits => 1;
4 - Parity => None;
5 - Receive interrupt for every byte of data shall be enabled
6 - Go to FH_Setup => FH_RFCommunication => FH_RFCommunication.c
    Insert the mentioned FH user defined code in Attention 1 + Attention 2 + Attention 3
7 - Include FH_RFCommunication_GlobalVariables.h in the receive ISR (Interrupt Service Routine) file
8 - Insert the mentioned FH user defined code in ISR (Interrupt Service Routine) to handle FH_RFCommunication_ReceiveBuf and FH_RFCommunication_ReceiveBufIndex

5 - Setup an interested Timer of your interested microcontroller:

1 - Interrupt for every 1 mili second shall be enabled
2 - Include FH_GlobalTimerCount.h in the ISR (Interrupt Service Routine) file
3 - Insert the mentioned FH user defined code in ISR (Interrupt Service Routine) to handle FH_GlobalTimeCounter

Example

1 - Setup a digital output pin (for example DO01 (Digital Output 01)) of your interested microcontroller:

1 - Write a function to Initialize the digital output pin
2 - Write a function to Set the digital output pin to the logic 1
3 - Write a function to Reset the digital output pin to the logic 0
4 - Go to FH_Function => FH_DO => FH_DO01 => FH_DO01.c
    Insert the mentioned FH user defined code in Attention 1 + Attention 2 + Attention 3 + Attention 4

2 - Connect the USB to Serial interface to the Communication Dedicated UART of your interested microcontroller :

1 - USB side to the computer
2 - TX and RX side to the microcontroller

3 - Run RIDE IDE

4 - Go to the test cases in TestCategoty1.robot

FH_RobotFramework => FH_TestSuites => TestSuite1 => TestCategoty1.robot

5 - Change the com port in ${SerialPortName} if it is not COM1 (According to your USB to Serial interface com port)

6 - Select (Tick by mouse click) DO_Init and DO_SetStatus test cases

7 - Go to Run tab

8 - Click on Start button

And then DO01 (Digital Output 01) is fully controllable from RobotFramework to be:

1 - Initialized

    ==============================================================================
                          ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${DO01}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DO}    Command=${DO_Commands_Init}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    DO
    Should Be Equal    ${ResultComponents}[2]    Init
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    DO01 => It indicates the Digital Output 01
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DO => It is the function in the message frame
    DO_Commands_Init => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|DO|Init|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = DO
    Log Many    Command =    ${ResultComponents}[2] => Command = Init
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    DO => If ${ResultComponents}[1] (Function) is not equal to "DO" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    Init => If ${ResultComponents}[2] (Command) is not equal to "Init" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

2 - Set

    ==============================================================================
                      ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${DO01}    ${DO_Set}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DO}    Command=${DO_Commands_SetStatus}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    DO
    Should Be Equal    ${ResultComponents}[2]    SetStatus
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    DO01 => It indicates the Digital Output 01
    DO_Set => It indicates the Digital Output 01 shall be Set (DO_Reset indicates the Digital Output 01 shall be Reset)
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DO => It is the function in the message frame
    DO_Commands_SetStatus => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|DO|SetStatus|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = DO
    Log Many    Command =    ${ResultComponents}[2] => Command = SetStatus
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    DO => If ${ResultComponents}[1] (Function) is not equal to "DO" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    SetStatus => If ${ResultComponents}[2] (Command) is not equal to "SetStatus" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

Then you could add another test case to Reset the DO01 (Digital Output 01) too:

    ==============================================================================
                      ##### RobotFramework Example #####
    ==============================================================================
    @{MessageData} =    Create List    ${DO01}    ${DO_Reset}
    &{Message} =    Create Dictionary    DeviceAddress=${DeviceAddress_01}    Function=${Function_DO}    Command=${DO_Commands_SetStatus}    Data=@{MessageData}
    ${Result}    SendMessage    &{Message}
    Log Many    Result =    ${Result}
    @{ResultComponents}=    split string    ${Result}    |
    Log Many    DeviceAddress =    ${ResultComponents}[0]
    Log Many    Function =    ${ResultComponents}[1]
    Log Many    Command =    ${ResultComponents}[2]
    Log Many    ErrorInformation =    ${ResultComponents}[3]
    Should Be Equal    ${ResultComponents}[0]    01
    Should Be Equal    ${ResultComponents}[1]    DO
    Should Be Equal    ${ResultComponents}[2]    SetStatus
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo}

    Comments:

    DO01 => It indicates the Digital Output 01
    DO_Reset => It indicates the Digital Output 01 shall be Reset (DO_Set indicates the Digital Output 01 shall be Set)
    DeviceAddress_01 => It shall be equal to the address of the device: FH_RFCommunication_DeviceAddress
    Function_DO => It is the function in the message frame
    DO_Commands_SetStatus => It is the command of the function in the message frame

    Result Example:

    Log Many    Result =    ${Result} => 01|DO|SetStatus|00|
    @{ResultComponents}=    split string    ${Result}    | => Split the result elements string by |
    Log Many    DeviceAddress =    ${ResultComponents}[0] => DeviceAddress = 01
    Log Many    Function =    ${ResultComponents}[1] => Function = DO
    Log Many    Command =    ${ResultComponents}[2] => Command = SetStatus
    Log Many    ErrorInformation =    ${ResultComponents}[3] => ErrorInformation = 00 (ERROR_NoInfo)
    Should Be Equal    ${ResultComponents}[0]    01 => If ${ResultComponents}[0] (DeviceAddress) is not equal to "01" then the test is not passed
    Should Be Equal    ${ResultComponents}[1]    DO => If ${ResultComponents}[1] (Function) is not equal to "DO" then the test is not passed
    Should Be Equal    ${ResultComponents}[2]    SetStatus => If ${ResultComponents}[2] (Command) is not equal to "SetStatus" then the test is not passed
    Should Be Equal    ${ResultComponents}[3]    ${ERROR_NoInfo} => If ${ResultComponents}[3] (ErrorInformation) is not equal to "${ERROR_NoInfo} (00)" then the test is not passed

📂 Explore the Source Files

For a detailed view of the project structure and to browse the source code directly within this documentation, please visit the file list page:

➔ Browse Source Code (files.html)

🤝 Contributing

Contributions are welcome!
